US Direct Type

PIBU-J1(120-277)
PIBG-J1(120-347)
Click to expand the criteria search box
  • Product number

  • {/php}
  • Rated power(W)

  • Output current(mA)

  • Output voltage(V)

  • Ripple

  • Dimmer way

US Direct Type Filter Models: 2 in total, please see the table below.

Series Rated power(W) Input voltage(V) Output current(mA) Output voltage(V) Efficiency Certificate Spec. PF Sample Application
PIBU-J1
20-50 120-277 540-1250 30-42 - UL FCC CUL
0.9/0.95
-
PIBU020C0540VSRJ01
20 120-277 540 30-42 86% UL FCC CUL
0.9/0.95
PIBU030C0800VSRJ01
30 120-277 800 30-42 87% UL FCC CUL
0.9/0.95
PIBU040C1050VSRJ01
40 120-277 1050 30-42 88% UL FCC CUL
0.9/0.95
PIBU050C1250VSRJ01
50 120-277 1250 30-42 89% UL FCC CUL
0.9/0.95
PIBG-J1
20-50 120-347 540-1250 30-42 - UL FCC CUL
0.9/0.95
-
PIBG020C0540VSRJ01
20 120-347 540 30-42 86% UL FCC CUL
0.9/0.95
PIBG030C0800VSRJ01
30 120-347 800 30-42 87% UL FCC CUL
0.9/0.95
PIBG040C1050VSRJ01
40 120-347 1050 30-42 88% UL FCC CUL
0.9/0.95
PIBG050C1250VSRJ01
50 120-347 1250 30-42 89% UL FCC CUL
0.9/0.95

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
