SMD Inductor
| Series | Inductance | Resistance | DCR | Load current | Dimension (mm) | Spec. | Sample Application |
| FASRF0504 | - | 190-4000 | 20-300 | 200-5000 | 4.8*5.0*5.20 | - | - |
| FASRF0504-191Y5R0 | - | 190 | 20 | 5000 | 4.8*5.0*5.20 | ||
| FASRF0504-302Y0R5 | - | 3000 | 200 | 500 | 4.8*5.0*5.20 | ||
| FASRF0504-351Y2R0 | - | 350 | 40 | 2000 | 4.8*5.0*5.20 | ||
| FASRF0504-402Y0R2 | - | 4000 | 300 | 200 | 4.8*5.0*5.20 | ||
| FASRF0504-102Y1R5 | - | 1000 | 60 | 1500 | 4.8*5.0*5.20 | ||
| FASRF0504-152Y1R0 | - | 1500 | 100 | 1000 | 4.8*5.0*5.20 | ||
| FACM09 | - | 220Ω | 0.3Ω | 650mA | 5.0*5.2*2.7 | - | |
| FACM09-1394A | - | 220Ω | 0.3Ω | 650mA | 5.0*5.2*2.7 | ||
| FACM10 | - | 120-220Ω | 0.12-0.3Ω | 300-650mA | 6.8*6.0*3.3 | - | |
| FACM10-121 | - | 120Ω | 0.3Ω | 650mA | 6.8*6.0*3.3 | ||
| FACM10-151 | - | 150Ω | 0.3Ω | 300mA | 6.8*6.0*3.3 | ||
| FACM10-161 | - | 160Ω | 0.3Ω | 300mA | 6.8*6.0*3.3 | ||
| FACM10-211 | - | 220Ω | 0.12Ω | 650mA | 6.8*6.0*3.3 | ||
| FASB0404SS | - | 334Ω | 100Ω | 3000mA | 3.8*4.9*5 | - | |
| FASB0404SS-334R | - | 334Ω | 100Ω | 3000mA | 3.8*4.9*5 | ||
| FASB0604 | - | 70-380Ω | 60-120Ω | 650-900mA | 5.85*6.25*3.6 | - | |
| FASB0604-015 | - | 70Ω | 60Ω | 900mA | 5.85*6.25*3.6 | ||
| FASB0604-025 | - | 180Ω | 65Ω | 800mA | 5.85*6.25*3.6 | ||
| FASB0604-035 | - | 280Ω | 80Ω | 700mA | 5.85*6.25*3.6 | ||
| FASB0604-045 | - | 360Ω | 120Ω | 650mA | 5.85*6.25*3.6 | ||
| FASCCM0608 | - | 65-90Ω | 2.5Ω | 130mA | 0.65*0.85*0.45 | - | |
| FASCCM0608-650 | - | 65Ω | 2.5Ω | 130mA | 0.65*0.85*0.45 | ||
| FASCCM0608-900 | - | 90Ω | 2.5Ω | 130mA | 0.65*0.85*0.45 | ||
| FASCCM1210CE | - | 90-200Ω | 1.75-2.7Ω | 130-160mA | 1.25*1.00*0.50 | - | |
| FASCCM1210CE-900 | - | 90Ω | 1.75Ω | 160mA | 1.25*1.00*0.50 | ||
| FASCCM1210CE-121 | - | 120Ω | 2.2Ω | 140mA | 1.25*1.00*0.50 | ||
| FASCCM1210CE-201 | - | 200Ω | 2.7Ω | 130mA | 1.25*1.00*0.50 | ||
| FASCCM2012 | - | 67-120Ω | 0.4-0.5Ω | 300-400mA | 2.00*1.25*1.00 | - | |
| FASCCM2012-670 | - | 67Ω | 0.4Ω | 400mA | 2.00*1.20*1.00 | ||
| FASCCM2012-900 | - | 90Ω | 0.4Ω | 400mA | 2.00*1.20*1.00 | ||
| FASCCM2012-121 | - | 120Ω | 0.4Ω | 400mA | 2.00*1.20*1.00 | ||
| FASCCM2012-161 | - | 160Ω | 0.5Ω | 400mA | 2.00*1.20*1.00 | ||
| FASCCM2012-181 | - | 180Ω | 0.5Ω | 400mA | 2.00*1.20*1.00 | ||
| FASCCM2012-221 | - | 220Ω | 0.5Ω | 300mA | 2.00*1.20*1.00 | ||
| FASCCM2012HS | - | 50-120Ω | 1.0-1.2Ω | 100-200mA | 2.00*1.20*1.00 | - | |
| FASCCM2012HSH-670A | - | 67Ω | 1.0Ω | 200mA | 2.00*1.25*1.00 | ||
| FASCCM2012HSH-900A | - | 90Ω | 1.0Ω | 200mA | 2.00*1.25*1.00 | ||
| FASCCM2012HSD-500A | - | 50Ω | 1.0Ω | 100mA | 2.00*1.25*1.00 | ||
| FASCCM2012HSD-900A | - | 90Ω | 1.0Ω | 200mA | 2.00*1.25*1.00 | ||
| FASCCM2012HSD-121A | - | 120Ω | 1.2Ω | 100mA | 2.00*1.25*1.00 | ||
| FASCCM2012HSS-500A | - | 50Ω | 1.0Ω | 100mA | 2.00*1.25*1.00 | ||
| FASCCM3216 | - | 90-120Ω | 0.5Ω | 500mA | 3.20*1.60*1.00 | - | |
| FASCCM3216-900 | - | 90Ω | 0.5Ω | 500mA | 3.20*1.60*1.00 | ||
| FASCCM3216-121 | - | 120Ω | 0.5Ω | 500mA | 3.20*1.60*1.00 | ||
| FASCM0805 | - | 200-5000Ω | 25-630Ω | 250-1400mA | 8.8*8.5*6.0 | - | |
| FASCM0805-121 | - | 200Ω | 25Ω | 1400mA | 8.8*8.5*6.0 | ||
| FASCM0805-251 | - | 400Ω | 30Ω | 1250mA | 8.8*8.5*6.0 | ||
| FASCM0805-501 | - | 800Ω | 60Ω | 900mA | 8.8*8.5*6.0 | ||
| FASCM0805-102 | - | 1400Ω | 180Ω | 500mA | 8.8*8.5*6.0 | ||
| FASCM0805-202 | - | 2000Ω | 250Ω | 450mA | 8.8*8.5*6.0 | ||
| FASCM0805-302 | - | 3000Ω | 300Ω | 400mA | 8.8*8.5*6.0 | ||
| FASCM0805-402 | - | 4000Ω | 580Ω | 300mA | 8.8*8.5*6.0 | ||
| FASCM0805-502 | - | 5000Ω | 630Ω | 250mA | 8.8*8.5*6.0 | ||
| FASCM0904 | - | 160-5000Ω | 120-700Ω | 400-1000mA | 9.00*5.50*4.70 | - | |
| FASCM0904-110 | - | 160Ω | 120Ω | 1000mA | 9.00*5.50*4.70 | ||
| FASCM0904-250 | - | 450Ω | 120Ω | 900mA | 9.00*5.50*4.70 | ||
| FASCM0904-10 | - | 800Ω | 150Ω | 800mA | 9.00*5.50*4.70 | ||
| FASCM0904-101 | - | 600Ω | 100Ω | 700mA | 9.00*5.50*4.70 | ||
| FASCM0904-471 | - | 1200Ω | 280Ω | 700mA | 9.00*5.50*4.70 | ||
| FASCM0904-102 | - | 1800Ω | 300Ω | 700mA | 9.00*5.50*4.70 | ||
| FASCM0904-222 | - | 3000Ω | 400Ω | 500mA | 9.00*5.50*4.70 | ||
| FASCM0904-472 | - | 5000Ω | 700Ω | 400mA | 9.00*5.50*4.70 | ||
| FASCM1006C | - | 200-5000Ω | 25-630Ω | 250-1400mA | 10.0*8.70*6.50 | - | |
| FASCM1006C-121 | - | 200Ω | 25Ω | 1400mA | 10.0*8.70*6.50 | ||
| FASCM1006C-251 | - | 400Ω | 30Ω | 1250mA | 10.0*8.70*6.50 | ||
| FASCM1006C-501 | - | 800Ω | 60Ω | 900mA | 10.0*8.70*6.50 | ||
| FASCM1006C-102 | - | 1400Ω | 180Ω | 500mA | 10.0*8.70*6.50 | ||
| FASCM1006C-202 | - | 2000Ω | 250Ω | 450mA | 10.0*8.70*6.50 | ||
| FASCM1006C-302 | - | 3000Ω | 300Ω | 400mA | 10.0*8.70*6.50 | ||
| FASCM1006C-402 | - | 4000Ω | 580Ω | 300mA | 10.0*8.70*6.50 | ||
| FASCM1006C-502 | - | 5000Ω | 630Ω | 250mA | 10.0*8.70*6.50 | ||
| FASCM1310 | - | 364-1567Ω | 50-91Ω | 2000-4500mA | 13.0*12.5*8.50 | - | |
| FASCM1310-364R | - | 364Ω | 50Ω | 3500mA | 13.0*12.5*8.50 | ||
| FASCM1310-400R | - | 330Ω | 50Ω | 2500mA | 13.0*12.5*8.50 | ||
| FASCM1310-412R | - | 325Ω | 50Ω | 4500mA | 13.0*12.5*8.50 | ||
| FASCM1310-1K5R | - | 1492Ω | 80Ω | 2500mA | 13.0*12.5*8.50 | ||
| FASCM1310-1K6R | - | 1567Ω | 91Ω | 2000mA | 13.0*12.5*8.50 | ||
| FASCMT0905 | - | 500-2200Ω | 7.5-60Ω | 1400-5000mA | 9.80*8.60*5.30 | - | |
| FASCMT0905-501 | - | 500Ω | 7.5Ω | 5000mA | 9.80*8.60*5.30 | ||
| FASCMT0905-801 | - | 800Ω | 15Ω | 3500mA | 9.80*8.60*5.30 | ||
| FASCMT0905-102 | - | 1000Ω | 35Ω | 2500mA | 9.80*8.60*5.30 | ||
| FASCMT0905-152 | - | 1500Ω | 50Ω | 2000mA | 9.80*8.60*5.30 | ||
| FASCMT0905-222 | - | 2200Ω | 60Ω | 1400mA | 9.80*8.60*5.30 | ||
| FASF1210HS | - | 12-90Ω | 0.2-0.3Ω | 400-450mA | 2.00*1.20*1.20 | - | |
| FASF1210HS-250 | - | 25Ω | 0.25Ω | 420mA | 2.00*1.20*1.20 | ||
| FASF1210HS-600 | - | 60Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF1210HS-900 | - | 90Ω | 0.3Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF1212HS-120 | - | 12Ω | 0.2Ω | 450mA | 2.00*1.20*1.20 | ||
| FASF1212HS-240 | - | 24Ω | 0.25Ω | 420mA | 2.00*1.20*1.20 | ||
| FASF1212HS-320 | - | 32Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF1212HS-670 | - | 67Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF1212HS-900 | - | 90Ω | 0.3Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF1211 | - | 80-2000Ω | 4.0-50.0Ω | 1500-10000mA | 12.0*12.5*10.8 | - | |
| FASF1211-800 | - | 80Ω | 4.0Ω | 10000mA | 12.0*12.5*10.8 | ||
| FASF1211-701 | - | 500Ω | 6.0Ω | 8000mA | 12.0*12.5*10.8 | ||
| FASF1211-102 | - | 750Ω | 14.0Ω | 6000mA | 12.0*12.5*10.8 | ||
| FASF1211-222 | - | 1700Ω | 35.0Ω | 1800mA | 12.0*12.5*10.8 | ||
| FASF1211-272 | - | 2000Ω | 50.0Ω | 1500mA | 12.0*12.5*10.8 | ||
| FASF1513 | - | 100-500Ω | 5.0-7.0Ω | 10000-13000mA | 15.0*15.5*13.0 | - | |
| FASF1513-301 | - | 100Ω | 5.0Ω | 13000mA | 15.0*15.5*13.0 | ||
| FASF1513-551 | - | 450Ω | 5.5Ω | 10000mA | 15.0*15.5*13.0 | ||
| FASF1513-701 | - | 500Ω | 7.0Ω | 10000mA | 15.0*15.5*13.0 | ||
| FASF1608LP | - | 10-160Ω | 0.3-0.8Ω | 200-500mA | 1.20*1.00*0.90 | - | |
| FASF1608LP-100 | - | 10Ω | 0.3Ω | 500mA | 1.20*1.00*0.90 | ||
| FASF1608LP-200 | - | 20Ω | 0.4Ω | 400mA | 1.20*1.00*0.90 | ||
| FASF1608LP-300 | - | 30Ω | 0.45Ω | 350mA | 1.20*1.00*0.90 | ||
| FASF1608LP-450 | - | 45Ω | 0.5Ω | 300mA | 1.20*1.00*0.90 | ||
| FASF1608LP-600 | - | 60Ω | 0.5Ω | 300mA | 1.20*1.00*0.90 | ||
| FASF1608LP-670 | - | 67Ω | 0.5Ω | 300mA | 1.20*1.00*0.90 | ||
| FASF1608LP-900 | - | 90Ω | 0.55Ω | 250mA | 1.20*1.00*0.90 | ||
| FASF1608LP-121 | - | 120Ω | 0.8Ω | 200mA | 1.20*1.00*0.90 | ||
| FASF1608LP-161 | - | 160Ω | 0.8Ω | 200mA | 1.20*1.00*0.90 | ||
| FASF2012HDMI | - | 40-120Ω | 0.25-0.30Ω | 370-400mA | 2.00*1.20*1.20 | - | |
| FASF2012HDMI-400 | - | 40Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012HDMI-670 | - | 67Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012HDMI-900 | - | 90Ω | 0.30Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012HDMI-121 | - | 120Ω | 0.30Ω | 370mA | 2.00*1.20*1.20 | ||
| FASF2012LP | - | 12-180Ω | 0.25-0.50Ω | 250-500mA | 2.00*1.20*1.20 | - | |
| FASF2012LP-120 | - | 12Ω | 0.25Ω | 500mA | 2.00*1.20*1.20 | ||
| FASF2012LP-90 | - | 90Ω | 0.35Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012LP-121 | - | 120Ω | 0.40Ω | 500mA | 2.00*1.20*1.20 | ||
| FASF2012LP-181 | - | 180Ω | 0.50Ω | 250mA | 2.00*1.20*1.20 | ||
| FASF2012 | - | 12-370Ω | 0.2-0.7Ω | 280-450mA | 2.00*1.20*1.20 | - | |
| FASF2012-120 | - | 12Ω | 0.2Ω | 450mA | 2.00*1.20*1.20 | ||
| FASF2012-240 | - | 24Ω | 0.25Ω | 420mA | 2.00*1.20*1.20 | ||
| FASF2012-320 | - | 32Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012-500 | - | 50Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012-670 | - | 67Ω | 0.25Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012-750 | - | 75Ω | 0.7Ω | 280mA | 2.00*1.20*1.20 | ||
| FASF2012-900 | - | 90Ω | 0.3Ω | 400mA | 2.00*1.20*1.20 | ||
| FASF2012-121 | - | 120Ω | 0.3Ω | 370mA | 2.00*1.20*1.20 | ||
| FASF2012-141 | - | 140Ω | 0.32Ω | 360mA | 2.00*1.20*1.20 | ||
| FASF2012-161 | - | 160Ω | 0.35Ω | 350mA | 2.00*1.20*1.20 | ||
| FASF2012-181 | - | 180Ω | 0.35Ω | 330mA | 2.00*1.20*1.20 | ||
| FASF2012-201 | - | 200Ω | 0.40Ω | 300mA | 2.00*1.20*1.20 | ||
| FASF2012-221 | - | 220Ω | 0.40Ω | 300mA | 2.00*1.20*1.20 | ||
| FASF2012-261 | - | 260Ω | 0.40Ω | 300mA | 2.00*1.20*1.20 | ||
| FASF2012-371 | - | 370Ω | 0.45Ω | 280mA | 2.00*1.20*1.20 | ||
| FASF3216 | - | 33-2200Ω | 0.20-1.20Ω | 200-400mA | 3.20*1.60*2.00 | - | |
| FASF3216-330 | - | 33Ω | 0.2Ω | 400mA | 3.20*1.60*2.00 | ||
| FASF3216-500 | - | 50Ω | 0.25Ω | 400mA | 3.20*1.60*2.00 | ||
| FASF3216-900 | - | 90Ω | 0.3Ω | 400mA | 3.20*1.60*2.00 | ||
| FASF3216-121 | - | 120Ω | 0.3Ω | 400mA | 3.20*1.60*2.00 | ||
| FASF3216-161 | - | 160Ω | 0.40Ω | 350mA | 3.20*1.60*2.00 | ||
| FASF3216-221 | - | 220Ω | 0.45Ω | 300mA | 3.20*1.60*2.00 | ||
| FASF3216-261 | - | 260Ω | 0.50Ω | 300mA | 3.20*1.60*2.00 | ||
| FASF3216-501 | - | 500Ω | 0.80Ω | 260mA | 3.20*1.60*2.00 | ||
| FASF3216-601 | - | 600Ω | 0.80Ω | 260mA | 3.20*1.60*2.00 | ||
| FASF3216-102 | - | 1000Ω | 1.00Ω | 250mA | 3.20*1.60*2.00 | ||
| FASF3216-222 | - | 2200Ω | 1.20Ω | 200mA | 3.20*1.60*2.00 | ||
| FASF4520 | - | 30-1200Ω | 35-81Ω | 1.9-3.2mA | 4.7*4.5*2.0 | - | |
| FASF4520-900 | - | 30Ω | 35Ω | 3.2mA | 4.7*4.5*2.0 | ||
| FASF4520-151 | - | 80Ω | 38Ω | 3.1mA | 4.7*4.5*2.0 | ||
| FASF4520-231 | - | 180Ω | 39Ω | 3.0mA | 4.7*4.5*2.0 | ||
| FASF4520-301 | - | 180Ω | 39Ω | 3.0mA | 4.7*4.5*2.0 | ||
| FASF4520-401 | - | 200Ω | 50Ω | 2.5mA | 4.7*4.5*2.0 | ||
| FASF4520-501 | - | 300Ω | 55Ω | 2.4mA | 4.7*4.5*2.0 | ||
| FASF4520-701 | - | 500Ω | 59Ω | 2.2mA | 4.7*4.5*2.0 | ||
| FASF4520-901 | - | 700Ω | 68Ω | 2.1mA | 4.7*4.5*2.0 | ||
| FASF4520-102 | - | 800Ω | 68Ω | 2.1mA | 4.7*4.5*2.0 | ||
| FASF4520-122 | - | 1000Ω | 74Ω | 2.0mA | 4.7*4.5*2.0 | ||
| FASF4520-142 | - | 1200Ω | 81Ω | 1.9mA | 4.7*4.5*2.0 | ||
| FASF453226L | - | 5800Ω | 2Ω | 250mA | 4.50*3.20*2.60 | - | |
| FASF453226L-101 | - | 5800Ω | 2.0Ω | 250mA | 4.50*3.20*2.60 | ||
| FASF453228L | - | 600-2800Ω | 0.6-1.0Ω | 200-250mA | 4.80*3.20*2.80 | - | |
| FASF453228L-110 | - | 600Ω | 0.6Ω | 250mA | 4.80*3.20*2.80 | ||
| FASF453228L-220 | - | 1200Ω | 1.0Ω | 200mA | 4.80*3.20*2.80 | ||
| FASF453228L-510 | - | 2800Ω | 1.0Ω | 200mA | 4.80*3.20*2.80 | ||
| FASF4532A | - | 11-100Ω | 0.60-2.00Ω | 150-250mA | 4.50*3.20*2.80 | - | |
| FASF4532A-110 | - | 60Ω | 0.60Ω | 250mA | 4.50*3.20*2.80 | ||
| FASF4532A-220 | - | 120Ω | 1.0Ω | 200mA | 4.50*3.20*2.80 | ||
| FASF4532A-510 | - | 280Ω | 1.0Ω | 200mA | 4.50*3.20*2.80 | ||
| FASF4532A-101 | - | 580Ω | 2.0Ω | 150mA | 4.50*3.20*2.80 | ||
| FASF4532 | - | 90-1400Ω | 0.05-0.12Ω | 2000-4000mA | 4.50*3.20*2.80 | - | |
| FASF4532-900 | - | 90Ω | 0.050Ω | 4000mA | 4.50*3.20*2.80 | ||
| FASF4532-231 | - | 230Ω | 0.051Ω | 3500mA | 4.50*3.20*2.80 | ||
| FASF4532-421 | - | 420Ω | 0.052Ω | 3200mA | 4.50*3.20*2.80 | ||
| FASF4532-601 | - | 600Ω | 0.065Ω | 2500mA | 4.50*3.20*2.80 | ||
| FASF4532-801 | - | 800Ω | 0.100Ω | 2300mA | 4.50*3.20*2.80 | ||
| FASF4532-901 | - | 900Ω | 0.100Ω | 2200mA | 4.50*3.20*2.80 | ||
| FASF4532-102 | - | 1000Ω | 0.110Ω | 2100mA | 4.50*3.20*2.80 | ||
| FASF4532-142 | - | 1400Ω | 0.120Ω | 2000mA | 4.50*3.20*2.80 | ||
| FASF4828 | - | 60-1400Ω | 0.1-0.4Ω | 1000-3000mA | 4.80*2.80*2.2 | - | |
| FASF4828-600 | - | 60Ω | 0.10Ω | 3000mA | 4.80*2.80*2.2 | ||
| FASF4828-121 | - | 120Ω | 0.20Ω | 2000mA | 4.80*2.80*2.2 | ||
| FASF4828-221 | - | 220Ω | 0.20Ω | 2000mA | 4.80*2.80*2.2 | ||
| FASF4828-601 | - | 600Ω | 0.20Ω | 2000mA | 4.80*2.80*2.2 | ||
| FASF4828-701 | - | 700Ω | 0.15Ω | 2000mA | 4.80*2.80*2.2 | ||
| FASF4828-102 | - | 1000Ω | 0.40Ω | 1000mA | 4.80*2.80*2.2 | ||
| FASF4828-122 | - | 1200Ω | 0.40Ω | 1000mA | 4.80*2.80*2.2 | ||
| FASF4828-142 | - | 1400Ω | 0.40Ω | 1000mA | 4.80*2.80*2.2 | ||
| FASF7060 | - | 40-2500Ω | 2-75Ω | 900-15000mA | 7.00*7.50*6.0 | - | |
| FASF7060-400 | - | 40Ω | 5Ω | 15000mA | 7.00*7.50*6.0 | ||
| FASF7060-101 | - | 100Ω | 10Ω | 9000mA | 7.00*7.50*6.0 | ||
| FASF7060-301 | - | 225Ω | 10Ω | 5000mA | 7.00*7.50*6.0 | ||
| FASF7060-501 | - | 400Ω | 10Ω | 5000mA | 7.00*7.50*6.0 | ||
| FASF7060-701 | - | 500Ω | 15Ω | 4000mA | 7.00*7.50*6.0 | ||
| FASF7060-102 | - | 750Ω | 17Ω | 3000mA | 7.00*7.50*6.0 | ||
| FASF7060-132 | - | 910Ω | 21Ω | 2500mA | 7.00*7.50*6.0 | ||
| FASF7060-272 | - | 2000Ω | 63Ω | 1000mA | 7.00*7.50*6.0 | ||
| FASF7060-302 | - | 2500Ω | 75Ω | 900mA | 7.00*7.50*6.0 | ||
| FASF9070 | - | 225-2500Ω | 6-90Ω | 1900-6000mA | 9.00*9.50*7.0 | - | |
| FASF9070-301 | - | 225Ω | 6Ω | 6000mA | 9.00*9.50*7.0 | ||
| FASF9070-501 | - | 400Ω | 8Ω | 5500mA | 9.00*9.50*7.0 | ||
| FASF9070-701 | - | 500Ω | 10Ω | 5000mA | 9.00*9.50*7.0 | ||
| FASF9070-102 | - | 750Ω | 13Ω | 4000mA | 9.00*9.50*7.0 | ||
| FASF9070-222 | - | 1700Ω | 60Ω | 2500mA | 9.00*9.50*7.0 | ||
| FASF9070-272 | - | 2000Ω | 86Ω | 2000mA | 9.00*9.50*7.0 | ||
| FASF9070-302 | - | 2500Ω | 90Ω | 1900mA | 9.00*9.50*7.0 | ||
| FASFB2012 | - | 50/50Ω,75/75Ω | 0.4-0.8Ω | 200-300mA | 2.00*1.20*1.20 | - | |
| FASFB2012-2011M01 | - | 50/50Ω | 0.80Ω | 200mA | 2.00*1.20*1.20 | ||
| FASFB2012-7511M01 | - | 75/75Ω | 0.77Ω | 200mA | 2.00*1.20*1.20 | ||
| FASFB2012-7511M02 | - | 75/75Ω | 0.40Ω | 300mA | 2.00*1.20*1.20 | ||
| FASFB2012-7511G01 | - | 75/75Ω | 0.42Ω | 290mA | 2.00*1.20*1.20 | ||
| FASFB2012-7511G02 | - | 75/75Ω | 0.42Ω | 290mA | 2.00*1.20*1.20 | ||
| FASFB2012-7511G03 | - | 75/75Ω | 0.42Ω | 290mA | 2.00*1.20*1.20 | ||
| FASMB275647M | - | 38Ω | 0.8Ω | 6000mA | 4.76*5.59*2.72 | - | |
| FASMB302520M | - | 30Ω | 0.8Ω | 6000mA | 3.0*2.5*2.0 | - | |
| FASMB403025M | - | 94Ω | 0.8Ω | 6000mA | 4.0*3.1*2.6 | - | |
| FASMB473029M | - | 47Ω | 0.8Ω | 6000mA | 4.7*3.0*2.9 | - | |
| FASMB488031M | - | 100Ω | 0.6Ω | 6000mA | 8.0*4.8*3.1 | - | |
| FASMB853025M | - | 90Ω | 1.2Ω | 6000mA | 8.5*3.1*2.6 | - | |
| FASMB903029M | - | 45Ω | 1.2Ω | 6000mA | 9.0*3.0*2.9 | - | |
| FASQD105T | - | 600-700Ω | 50-55Ω | 3000-4000mA | 10.0*8.0*5.0 | - | |
| FASQD105T-3T | - | 600Ω | 50Ω | 4000mA | 10.0*8.0*5.0 | ||
| FASQD105T-4T | - | 700Ω | 55Ω | 3000mA | 10.0*8.0*5.0 | ||
| FASQD125T | - | 200-400Ω | 15-25Ω | 5000-6000mA | 12.0*10.0*6.0 | - | |
| FASQD125T-2T | - | 200Ω | 15Ω | 6000mA | 12.0*10.0*6.0 | ||
| FASQD125T-3T | - | 300Ω | 20Ω | 5500mA | 12.0*10.0*6.0 | ||
| FASQD125T-4T | - | 400Ω | 25Ω | 5000mA | 12.0*10.0*6.0 | ||
| FASQD50T | - | 600-700Ω | 50-55Ω | 3000-4000mA | 5.0*8.5*5.0 | - | |
| FASQD50T-3T | - | 600Ω | 50Ω | 3000mA | 5.0*8.5*5.0 | ||
| FASQD50T-4T | - | 700Ω | 55Ω | 4000mA | 5.0*8.5*5.0 | ||
| FASQD57T | - | 150-350Ω | 50-70Ω | 500-1000mA | 5.7*4.6*1.7 | - | |
| FASQD57T-1T | - | 150Ω | 50Ω | 1000mA | 5.7*4.6*1.7 | ||
| FASQD57T-2T | - | 350Ω | 70Ω | 500mA | 5.7*4.6*1.7 | ||
| FASQD75T | - | 200-600Ω | 20-45Ω | 1000-2000mA | 7.5*6.0*3.2 | - | |
| FASQD75T-2T | - | 200Ω | 20Ω | 2000mA | 7.5*6.0*3.2 | ||
| FASQD75T-3T | - | 300Ω | 25Ω | 1500mA | 7.5*6.0*3.2 | ||
| FASQD75T-4T | - | 600Ω | 45Ω | 1000mA | 7.5*6.0*3.2 | ||
| FASRF5025 | - | 100-1400Ω | 9-40Ω | 1500-6500mA | 4.8*5.0*2.50 | - | |
| FASRF5025-101 | - | 100Ω | 9Ω | 6500mA | 4.8*5.0*2.50 | ||
| FASRF5025-251 | - | 250Ω | 14Ω | 5000mA | 4.8*5.0*2.50 | ||
| FASRF5025-351 | - | 350Ω | 28Ω | 4000mA | 4.8*5.0*2.50 | ||
| FASRF5025-501 | - | 500Ω | 19Ω | 4000mA | 4.8*5.0*2.50 | ||
| FASRF5025-102 | - | 1000Ω | 24Ω | 2000mA | 4.8*5.0*2.50 | ||
| FASRF5025-142 | - | 1400Ω | 40Ω | 1500mA | 4.8*5.0*2.50 | ||
| FASDRH1206B | 1.00-820 | - | 7.80-1700 | 0.63-10.0 | - | - | - |
| FASDRH1206B-1R0Y10R0 | 1.00 | - | 7.80 | 10.0 | - | ||
| FASDRH1206B-1R2Y9R8 | 1.20 | - | 8.00 | 9.80 | - | ||
| FASDRH1206B-1R5Y9R0 | 1.50 | - | 9.50 | 9.00 | - | ||
| FASDRH1206B-2R2Y8R5 | 2.20 | - | 10.5 | 8.50 | - | ||
| FASDRH1206B-2R4Y8R0 | 2.40 | - | 11.5 | 8.00 | - | ||
| FASDRH1206B-3R3Y7R8 | 3.30 | - | 12.0 | 7.80 | - | ||
| FASDRH1206B-3R5Y7R6 | 3.50 | - | 13.0 | 7.60 | - | ||
| FASDRH1206B-4R7Y7R0 | 4.70 | - | 15.5 | 7.00 | - | ||
| FASDRH1206B-5R6Y6R9 | 5.60 | - | 16.2 | 6.90 | - | ||
| FASDRH1206B-6R1Y6R8 | 6.10 | - | 17.0 | 6.80 | - | ||
| FASDRH1206B-6R8Y6R5 | 6.80 | - | 18.0 | 6.50 | - | ||
| FASDRH1206B-7R6Y6R2 | 7.60 | - | 19.0 | 6.20 | - | ||
| FASDRH1206B-8R2Y5R8 | 8.20 | - | 19.5 | 5.80 | - | ||
| FASDRH1206B-100M5R5 | 10.0 | - | 20.0 | 5.50 | - | ||
| FASDRH1206B-101M1R7 | 100 | - | 180.0 | 1.70 | - | ||
| FASDRH1206B-102K0R6 | 1000 | - | 1700.0 | 0.60 | - | ||
| FASDRH1206B-120M5R0 | 12.0 | - | 23.0 | 5.00 | - | ||
| FASDRH1206B-121K1R65 | 120 | - | 210.0 | 1.65 | - | ||
| FASDRH1206B-150M4R6 | 15.0 | - | 23.0 | 4.60 | - | ||
| FASDRH1206B-151K1R55 | 150 | - | 260.0 | 1.55 | - | ||
| FASDRH1206B-180M3R9 | 18.0 | - | 27.0 | 3.90 | - | ||
| FASDRH1206B-181K1R4 | 180 | - | 320.0 | 1.40 | - | ||
| FASDRH1206B-220M3R7 | 22.0 | - | 36.0 | 3.70 | - | ||
| FASDRH1206B-221K1R3 | 220 | - | 380.0 | 1.30 | - | ||
| FASDRH1206B-270M3R3 | 27.0 | - | 43.0 | 3.30 | - | ||
| FASDRH1206B-271K1R2 | 270 | - | 450.0 | 1.20 | - | ||
| FASDRH1206B-330M2R8 | 33.0 | - | 60.0 | 2.80 | - | ||
| FASDRH1206B-331K1R1 | 330 | - | 580.0 | 1.10 | - | ||
| FASDRH1206B-390M2R7 | 39.0 | - | 70.0 | 2.70 | - | ||
| FASDRH1206B-391K1R0 | 390 | - | 700.0 | 1.00 | - | ||
| FASDRH1206B-470M2R5 | 47.0 | - | 86.0 | 2.50 | - | ||
| FASDRH1206B-471K0R9 | 470 | - | 820.0 | 0.90 | - | ||
| FASDRH1206B-560M2R2 | 56.0 | - | 100.0 | 2.20 | - | ||
| FASDRH1206B-561K0R8 | 560 | - | 1000.0 | 0.80 | - | ||
| FASDRH1206B-680M2R1 | 68.0 | - | 110.0 | 2.10 | - | ||
| FASDRH1206B-681K0R75 | 680 | - | 1150.0 | 0.75 | - | ||
| FASDRH1206B-820M1R9 | 82.0 | - | 145.0 | 1.90 | - | ||
| FASDRH1206B-821K0R63 | 820 | - | 1500.0 | 0.63 | - | ||
| FAHPI0412 | 0.15-4.70uH | - | 0.009-0.195Ω | 2200-15000mA | - | - | |
| FAHPI0412-1R0M5R5 | 1.00uH | - | 0.0470Ω | 5500mA | - | ||
| FAHPI0412-1R5M4R0 | 1.50uH | - | 0.0750Ω | 4000mA | - | ||
| FAHPI0412-2R2M3R0 | 2.20uH | - | 0.0835Ω | 3000mA | - | ||
| FAHPI0412-4R7M2R2 | 4.70uH | - | 0.1950Ω | 2200mA | - | ||
| FAHPI0412-R15M15R0 | 0.15uH | - | 0.0090Ω | 15000mA | - | ||
| FAHPI0412-R22M11R0 | 0.22uH | - | 0.0110Ω | 11000mA | - | ||
| FAHPI0412-R33M8R4 | 0.33uH | - | 0.0190Ω | 8400mA | - | ||
| FAHPI0412-R47M6R8 | 0.47uH | - | 0.0210Ω | 6800mA | - | ||
| FAHPI0412-R68M6R0 | 0.68uH | - | 0.0360Ω | 6000mA | - | ||
| FAHPI0420 | 0.10-22.00uH | - | 0.0066-0.3630Ω | 1400-22000mA | - | - | |
| FAHPI0420-1R0M7R0 | 1.00uH | - | 0.0270Ω | 7000mA | - | ||
| FAHPI0420-1R2M6R5 | 1.20uH | - | 0.0270Ω | 6500mA | - | ||
| FAHPI0420-1R5M5R5 | 1.50uH | - | 0.0460Ω | 5500mA | - | ||
| FAHPI0420-2R2M5R0 | 2.20uH | - | 0.0580Ω | 5000mA | - | ||
| FAHPI0420-3R3M3R5 | 3.30uH | - | 0.0870Ω | 3500mA | - | ||
| FAHPI0420-4R7M3R0 | 4.70uH | - | 0.1050Ω | 3000mA | - | ||
| FAHPI0420-6R8M2R5 | 6.80uH | - | 0.1750Ω | 2500mA | - | ||
| FAHPI0420-100M2R0 | 10.00uH | - | 0.2820Ω | 2000mA | - | ||
| FAHPI0420-220M1R4 | 22.00uH | - | 0.3630Ω | 1400mA | - | ||
| FAHPI0420-R10M22R0 | 0.10uH | - | 0.0040Ω | 22000mA | - | ||
| FAHPI0420-R22M12R5 | 0.22uH | - | 0.0066Ω | 12500mA | - | ||
| FAHPI0420-R33M12R0 | 0.33uH | - | 0.0110Ω | 12000mA | - | ||
| FAHPI0420-R47M9R5 | 0.47uH | - | 0.0140Ω | 9500mA | - | ||
| FAHPI0420-R56M9R0 | 0.56uH | - | 0.0160Ω | 9000mA | - | ||
| FAHPI0420-R68M8R0 | 0.68uH | - | 0.0180Ω | 8000mA | - | ||
| FAHPI0518 | 0.47-10.00uH | - | 0.009-0.155Ω | 3000-15500mA | - | - | |
| FAHPI0518-1R0M | 1.00uH | - | 0.0170Ω | 9000mA | - | ||
| FAHPI0518-1R5M8R0 | 1.50uH | - | 0.0260Ω | 8000mA | - | ||
| FAHPI0518-2R2M6R5 | 2.20uH | - | 0.0350Ω | 6500mA | - | ||
| FAHPI0518-3R3M5R0 | 3.30uH | - | 0.0580Ω | 5000mA | - | ||
| FAHPI0518-4R7M | 4.70uH | - | 0.0850Ω | 4000mA | - | ||
| FAHPI0518-6R8M3R4 | 6.80uH | - | 0.1200Ω | 3400mA | - | ||
| FAHPI0518-100M3R0 | 10.00uH | - | 0.1550Ω | 3000mA | - | ||
| FAHPI0518-R47M15R5 | 0.47uH | - | 0.0090Ω | 15500mA | - | ||
| FAHPI0518-R56M15R0 | 0.56uH | - | 0.0100Ω | 15000mA | - | ||
| FAHPI0518-R68M11R2 | 0.68uH | - | 0.1380Ω | 11200mA | - | ||
| FAHPI0530 | 0.10-10.00uH | - | 0.003-0.125Ω | 3500-30000mA | - | - | |
| FAHPI0530-1R0M10R0 | 1.00uH | - | 0.0140Ω | 10000mA | - | ||
| FAHPI0530-1R2M9R5 | 1.20uH | - | 0.0160Ω | 9500mA | - | ||
| FAHPI0530-1R5M9R0 | 1.50uH | - | 0.0250Ω | 9000mA | - | ||
| FAHPI0530-2R2M7R0 | 2.20uH | - | 0.0290Ω | 7000mA | - | ||
| FAHPI0530-3R3M6R0 | 3.30uH | - | 0.0380Ω | 6000mA | - | ||
| FAHPI0530-4R7M4R6 | 4.70uH | - | 0.0600Ω | 4600mA | - | ||
| FAHPI0530-6R8M3R6 | 6.80uH | - | 0.0900Ω | 3600mA | - | ||
| FAHPI0530-100M3R5 | 10.00uH | - | 0.1250Ω | 3500mA | - | ||
| FAHPI0530-R10M30R0 | 0.10uH | - | 0.0030Ω | 30000mA | - | ||
| FAHPI0530-R20M20R0 | 0.20uH | - | 0.0039Ω | 20000mA | - | ||
| FAHPI0530-R33M18R0 | 0.33uH | - | 0.0055Ω | 18000mA | - | ||
| FAHPI0530-R47M15R0 | 0.47uH | - | 0.0085Ω | 15000mA | - | ||
| FAHPI0530-R68M11R5 | 0.68uH | - | 0.0120Ω | 9000mA | - | ||
| FAHPI0615 | 0.47-10.00uH | - | 0.0085-0.175Ω | 3000-16000mA | - | - | |
| FAHPI0615-1R0M9R0 | 1.00uH | - | 0.0210Ω | 9000mA | - | ||
| FAHPI0615-2R2M7R0 | 2.20uH | - | 0.0540Ω | 7000mA | - | ||
| FAHPI0615-3R3M5R5 | 3.30uH | - | 0.0630Ω | 5500mA | - | ||
| FAHPI0615-4R7M5R0 | 4.70uH | - | 0.0850Ω | 5000mA | - | ||
| FAHPI0615-6R8M4R0 | 6.80uH | - | 0.1350Ω | 4000mA | - | ||
| FAHPI0615-100M3R0 | 10.0uH | - | 0.1750Ω | 3000mA | - | ||
| FAHPI0615-R47M16R0 | 0.47uH | - | 0.0085Ω | 16000mA | - | ||
| FAHPI0615-R56M14R0 | 0.56uH | - | 0.0110Ω | 14000mA | - | ||
| FAHPI0615-R68M12R0 | 0.68uH | - | 0.0120Ω | 12000mA | - | ||
| FAHPI0615-R82M10R0 | 0.82uH | - | 0.0170Ω | 10000mA | - | ||
| FAHPI0618 | 0.10-22.00uH | - | 0.0023-0.35Ω | 1200-38000mA | - | - | |
| FAHPI0618-1R0M12R0 | 1.00uH | - | 0.0160Ω | 1200mA | - | ||
| FAHPI0618-1R5M9R2 | 1.50uH | - | 0.0260Ω | 9200mA | - | ||
| FAHPI0618-2R2M8R0 | 2.20uH | - | 0.0350Ω | 8000mA | - | ||
| FAHPI0618-3R3M6R0 | 3.30uH | - | 0.0500Ω | 6000mA | - | ||
| FAHPI0618-4R7M5R0 | 4.70uH | - | 0.0620Ω | 5000mA | - | ||
| FAHPI0618-6R8M4R5 | 6.80uH | - | 0.1100Ω | 4500mA | - | ||
| FAHPI0618-100M4R0 | 10.00uH | - | 0.1550Ω | 4000mA | - | ||
| FAHPI0618-220M2R3 | 22.00uH | - | 0.3500Ω | 2300mA | - | ||
| FAHPI0618-R10M38R0 | 0.10uH | - | 0.0023Ω | 38000mA | - | ||
| FAHPI0618-R22M24R0 | 0.22uH | - | 0.0035Ω | 24000mA | - | ||
| FAHPI0618-R47M18R0 | 0.47uH | - | 0.0084Ω | 18000mA | - | ||
| FAHPI0618-R68M16R5 | 0.68uH | - | 0.0120Ω | 16500mA | - | ||
| FAHPI0624 | 0.22-22.0uH | - | 0.003-0.23Ω | 2500-34000mA | - | - | |
| FAHPI0624-1R0M15R0 | 1uH | - | 0.0135Ω | 15000mA | - | ||
| FAHPI0624-1R5M13R5 | 1.50uH | - | 0.0200Ω | 13500mA | - | - | |
| FAHPI0624-2R2M10R0 | 2.20uH | - | 0.0280Ω | 10000mA | - | ||
| FAHPI0624-3R3M8R0 | 3.30uH | - | 0.0390Ω | 8000mA | - | ||
| FAHPI0624-4R7M6R5 | 4.70uH | - | 0.0500Ω | 6500mA | - | ||
| FAHPI0624-6R8M6R0 | 6.80uH | - | 0.0700Ω | 6000mA | - | ||
| FAHPI0624-100M4R0 | 10.00uH | - | 0.1010Ω | 4000mA | - | ||
| FAHPI0624-150M3R3 | 15.00uH | - | 0.1600Ω | 3300mA | - | ||
| FAHPI0624-220M2R5 | 22.00uH | - | 0.2300Ω | 2500mA | - | ||
| FAHPI0624-R22M34R0 | 0.22uH | - | 0.0030Ω | 34000mA | - | ||
| FAHPI0624-R33M24R5 | 0.33uH | - | 0.0041Ω | 24500mA | - | ||
| FAHPI0624-R47M22R0 | 0.47uH | - | 0.0051Ω | 22000mA | - | ||
| FAHPI0624-R56M17R0 | 0.56uH | - | 0.0065Ω | 17000mA | - | ||
| FAHPI0624-R68M16R0 | 0.68uH | - | 0.0070Ω | 16000mA | - | ||
| FAHPI0630 | 0.22-47.0uH | - | 0.003-0.385Ω | 2000-25000mA | - | - | |
| FAHPI0630-1R0M15R0 | 1.00uH | - | 0.0074Ω | 15000mA | - | ||
| FAHPI0630-1R5M | 1.50uH | - | 0.0121Ω | 12000mA | - | ||
| FAHPI0630-2R2M10R0 | 2.20uH | - | 0.0150Ω | 10000mA | - | ||
| FAHPI0630-3R3M9R5 | 3.30uH | - | 0.0220Ω | 9500mA | - | ||
| FAHPI0630-4R7M | 4.70uH | - | 0.0330Ω | 9000mA | - | ||
| FAHPI0630-5R6M6R5 | 5.60uH | - | 0.0420Ω | 6500mA | - | ||
| FAHPI0630-6R8M6R0 | 6.80uH | - | 0.0480Ω | 6000mA | - | ||
| FAHPI0630-8R2M5R5 | 8.20uH | - | 0.0600Ω | 5500mA | - | ||
| FAHPI0630-100M5R5 | 10.00uH | - | 0.0680Ω | 5500mA | - | ||
| FAHPI0630-150M4R0 | 15.00uH | - | 0.1130Ω | 4000mA | - | ||
| FAHPI0630-220M3R0 | 22.00uH | - | 0.1700Ω | 3000mA | - | ||
| FAHPI0630-330M2R5 | 33.00uH | - | 0.2700Ω | 2500mA | - | ||
| FAHPI0630-470M2R0 | 47.00uH | - | 0.3850Ω | 2000mA | - | ||
| FAHPI0630-R22M34R0 | 0.22uH | - | 0.0030Ω | 3400mA | - | ||
| FAHPI0630-R33M25R0 | 0.33uH | - | 0.0035Ω | 25000mA | - | ||
| FAHPI0630-R47M20R0 | 0.47uH | - | 0.0041Ω | 20000mA | - | ||
| FAHPI0630-R56M18R0 | 0.56uH | - | 0.0045Ω | 18000mA | - | ||
| FAHPI0630-R68M17R0 | 0.68uH | - | 0.0053Ω | 17000mA | - | ||
| FAHPI0630-R82M16R0 | 0.82uH | - | 0.0060Ω | 16000mA | - | ||
| FAHPI0640 | 0.68-47.00uH | - | 0.0048-0.32Ω | 2500-19000mA | - | - | |
| FAHPI0640-1R0M16R0 | 1.00uH | - | 0.0066Ω | 16000mA | - | ||
| FAHPI0640-1R5M12R5 | 1.50uH | - | 0.0100Ω | 12500mA | - | ||
| FAHPI0640-2R2M11R0 | 2.20uH | - | 0.0140Ω | 11000mA | - | ||
| FAHPI0640-3R3M9R5 | 3.30uH | - | 0.0200Ω | 9500mA | - | ||
| FAHPI0640-4R7M9R0 | 4.70uH | - | 0.0300Ω | 9000mA | - | ||
| FAHPI0640-6R8M6R5 | 6.80uH | - | 0.0450Ω | 6500mA | - | ||
| FAHPI0640-100M6R0 | 10.00uH | - | 0.0650Ω | 6000mA | - | ||
| FAHPI0640-150M4R5 | 15.00uH | - | 0.0950Ω | 4500mA | - | ||
| FAHPI0640-220M4R0 | 22.00uH | - | 0.1250Ω | 4000mA | - | ||
| FAHPI0640-330M3R0 | 33.00uH | - | 0.2400Ω | 3000mA | - | ||
| FAHPI0640-470M2R5 | 47.00uH | - | 0.3200Ω | 2500mA | - | ||
| FAHPI0640-R68M19R0 | 0.68uH | - | 0.0048Ω | 19000mA | - | ||
| FAHPI0650 | 0.47-47.0uH | - | 0.0039-0.2300Ω | 2600-21000mA | - | - | |
| FAHPI0650-1R0M16R0 | 1.00uH | - | 0.0066Ω | 16000mA | - | ||
| FAHPI0650-1R5M13R0 | 1.50uH | - | 0.0100Ω | 13000mA | - | ||
| FAHPI0650-2R2M11R0 | 2.20uH | - | 0.0125Ω | 11000mA | - | ||
| FAHPI0650-3R3M10R0 | 3.30uH | - | 0.0220Ω | 10000mA | - | ||
| FAHPI0650-4R7M8R0 | 4.70uH | - | 0.0290Ω | 8000mA | - | ||
| FAHPI0650-6R8M6R3 | 6.80uH | - | 0.0410Ω | 6300mA | - | ||
| FAHPI0650-8R2M5R5 | 8.20uH | - | 0.0480Ω | 5500mA | - | ||
| FAHPI0650-100M5R3 | 10.00uH | - | 0.0600Ω | 5300mA | - | ||
| FAHPI0650-150M4R0 | 15.00uH | - | 0.0900Ω | 4000mA | - | ||
| FAHPI0650-220M3R5 | 22.00uH | - | 0.1400Ω | 3500mA | - | ||
| FAHPI0650-330M3R0 | 33.00uH | - | 0.1900Ω | 3000mA | - | ||
| FAHPI0650-470M2R6 | 47.00uH | - | 0.2300Ω | 2600mA | - | ||
| FAHPI0650-R47M21R0 | 0.47uH | - | 0.0039Ω | 21000mA | - | ||
| FAHPI0650-R68M18R0 | 0.68uH | - | 0.0045Ω | 18000mA | - | ||
| FAHPI1030 | 0.22-33.0uH | - | 0.0012-0.1600Ω | 4000-50000mA | - | - | - |
| FAHPI1030-1R0M21R0 | 1.00uH | - | 0.0060Ω | 21000mA | - | ||
| FAHPI1030-2R2M14R0 | 2.20uH | - | 0.0090Ω | 14000mA | - | ||
| FAHPI1030-3R3M12R0 | 3.30uH | - | 0.0160Ω | 12000mA | - | ||
| FAHPI1030-4R7M10R0 | 4.70uH | - | 0.0240Ω | 24000mA | - | ||
| FAHPI1030-8R2M7R0 | 8.20uH | - | 0.0450Ω | 7000mA | - | ||
| FAHPI1030-330M4R0 | 33.00uH | - | 0.1600Ω | 4000mA | - | ||
| FAHPI1030-R22M50R0 | 0.22uH | - | 0.0012Ω | 50000mA | - | ||
| FAHPI1030-R33M32R0 | 0.33uH | - | 0.0016Ω | 32000mA | - | ||
| FAHPI1030-R36M28R0 | 0.36uH | - | 0.0016Ω | 28000mA | - | ||
| FAHPI1030-R47M26R0 | 0.47uH | - | 0.0025Ω | 26000mA | - | ||
| FAHPI1030-R82M23R0 | 0.82uH | - | 0.0037Ω | 23000mA | - | ||
| FAHPI1040 | 0.22-68.0uH | - | 0.0010-0.195Ω | 3000-60000mA | - | - | |
| FAHPI1040-1R0M28R0 | 1.00uH | - | 0.0033Ω | 28000mA | - | ||
| FAHPI1040-1R5M24R0 | 1.50uH | - | 0.0042Ω | 24000mA | - | ||
| FAHPI1040-2R2M16R5 | 2.20uH | - | 0.0070Ω | 16500mA | - | ||
| FAHPI1040-3R3M16R0 | 3.30uH | - | 0.0118Ω | 16000mA | - | ||
| FAHPI1040-4R7M13R0 | 4.70uH | - | 0.0200Ω | 13000mA | - | ||
| FAHPI1040-6R8M12R0 | 6.80uH | - | 0.0250Ω | 12000mA | - | ||
| FAHPI1040-8R2M9R0 | 8.20uH | - | 0.0270Ω | 9000mA | - | ||
| FAHPI1040-100M8R5 | 10.00uH | - | 0.0350Ω | 8500mA | - | ||
| FAHPI1040-150M7R0 | 15.00uH | - | 0.0450Ω | 7000mA | - | ||
| FAHPI1040-220M5R5 | 22.00uH | - | 0.0660Ω | 5500mA | - | ||
| FAHPI1040-330M4R8 | 33.00uH | - | 0.0920Ω | 4800mA | - | ||
| FAHPI1040-470M3R5 | 47.00uH | - | 0.1450Ω | 3500mA | - | ||
| FAHPI1040-680M3R0 | 68.00uH | - | 0.1950Ω | 3000mA | - | ||
| FAHPI1040-R22M60R0 | 0.22uH | - | 0.0010Ω | 60000mA | - | ||
| FAHPI1040-R30M45R0 | 0.30uH | - | 0.0011Ω | 45000mA | - | ||
| FAHPI1040-R36M45R0 | 0.36uH | - | 0.0012Ω | 45000mA | - | ||
| FAHPI1040-R47M40R0 | 0.47uH | - | 0.0017Ω | 40000mA | - | - | |
| FAHPI1040-R56M33R0 | 0.56uH | - | 0.0018Ω | 33000mA | - | - | |
| FAHPI1040-R68M30R0 | 0.68uH | - | 0.0024Ω | 30000mA | - | - | |
| FAHPI1040-R80M29R0 | 0.80uH | - | 0.0027Ω | 29000mA | - | - | |
| FAHPI1050 | 0.22-100.0uH | - | 0.0008-0.2900Ω | 2800-65000mA | - | - | - |
| FAHPI1050-1R0M30R0 | 1.00uH | - | 0.0030Ω | 30000mA | - | ||
| FAHPI1050-1R5M25R0 | 1.50uH | - | 0.0038Ω | 25000mA | - | ||
| FAHPI1050-2R2M19R0 | 2.20uH | - | 0.0060Ω | 19000mA | - | ||
| FAHPI1050-3R3M16R0 | 3.30uH | - | 0.0100Ω | 16000mA | - | ||
| FAHPI1050-4R7M15R0 | 4.70uH | - | 0.0140Ω | 15000mA | - | ||
| FAHPI1050-5R6M14R0 | 5.60uH | - | 0.0170Ω | 14000mA | - | ||
| FAHPI1050-6R8M14R0 | 6.80uH | - | 0.0185Ω | 14000mA | - | ||
| FAHPI1050-100M10R0 | 10.00uH | - | 0.0280Ω | 10000mA | - | ||
| FAHPI1050-101M2R8 | 100.00uH | - | 0.2900Ω | 2800mA | - | ||
| FAHPI1050-150M7R5 | 15.00uH | - | 0.0420Ω | 7500mA | - | ||
| FAHPI1050-220M6R0 | 22.00uH | - | 0.0500Ω | 6000mA | - | ||
| FAHPI1050-330M5R2 | 33.00uH | - | 0.0860Ω | 5200mA | - | ||
| FAHPI1050-470M4R5 | 47.00uH | - | 0.1270Ω | 4500mA | - | ||
| FAHPI1050-R22M65R0 | 0.22uH | - | 0.0008Ω | 65000mA | - | ||
| FAHPI1240 | 0.22-22.0uH | - | 0.0009-0.051Ω | 6000-48000mA | - | - | - |
| FAHPI1240-1R0M35R0 | 1.00uH | - | 0.0075Ω | 35000mA | - | ||
| FAHPI1240-1R5M30R5 | 1.50uH | - | 0.0095Ω | 30500mA | - | ||
| FAHPI1240-2R2M26R0 | 2.20uH | - | 0.0115Ω | 26000mA | - | ||
| FAHPI1240-3R3M21R0 | 3.30uH | - | 0.0130Ω | 21000mA | - | ||
| FAHPI1240-4R7M18R0 | 4.70uH | - | 0.0145Ω | 18000mA | - | ||
| FAHPI1240-6R8M14R0 | 6.80uH | - | 0.0200Ω | 14000mA | - | ||
| FAHPI1240-100M10R0 | 10.00uH | - | 0.0250Ω | 10000mA | - | ||
| FAHPI1240-150M7R5 | 15.00uH | - | 0.0390Ω | 7500mA | - | ||
| FAHPI1240-220M6R0 | 22.00uH | - | 0.0510Ω | 6000mA | - | ||
| FAHPI1240-R22M50R0 | 0.22uH | - | 0.0009Ω | 50000mA | - | ||
| FAHPI1240-R47M48R0 | 0.47uH | - | 0.0020Ω | 48000mA | - | ||
| FAHPI1240-R68M47R0 | 0.68uH | - | 0.0035Ω | 47000mA | - | ||
| FAHPI1240-R82M40R0 | 0.82uH | - | 0.0045Ω | 40000mA | - | ||
| FAHPI1250 | 0.22-47.00uH | - | 0.0007-0.13Ω | 3900-35000mA | - | - | - |
| FAHPI1250-1R0M35R0 | 1.00uH | - | 0.0022Ω | 35000mA | - | ||
| FAHPI1250-1R5M33R0 | 1.50uH | - | 0.0032Ω | 33000mA | - | ||
| FAHPI1250-2R2M24R0 | 2.20uH | - | 0.0050Ω | 24000mA | - | ||
| FAHPI1250-3R3M22R0 | 3.30uH | - | 0.0070Ω | 22000mA | - | ||
| FAHPI1250-4R7M20R0 | 4.70uH | - | 0.0090Ω | 20000mA | - | ||
| FAHPI1250-6R8M16R0 | 6.80uH | - | 0.0180Ω | 16000mA | - | ||
| FAHPI1250-8R2M13R0 | 8.20uH | - | 0.0200Ω | 13000mA | - | ||
| FAHPI1250-100M12R0 | 10.00uH | - | 0.0220Ω | 12000mA | - | ||
| FAHPI1250-150M10R0 | 15.00uH | - | 0.0300Ω | 10000mA | - | ||
| FAHPI1250-220M6R5 | 22.00uH | - | 0.0580Ω | 6500mA | - | ||
| FAHPI1250-330M6R0 | 33.00uH | - | 0.0840Ω | 6000mA | - | ||
| FAHPI1250-470M5R0 | 47.00uH | - | 0.1300Ω | 5000mA | - | ||
| FAHPI1250-R22M75R0 | 0.22uH | - | 0.0007Ω | 7500mA | - | ||
| FAHPI1250-R36M50R0 | 0.36uH | - | 0.0008Ω | 5000mA | - | ||
| FAHPI1250-R50M48R0 | 0.50uH | - | 0.0012Ω | 4800mA | - | ||
| FAHPI1250-R68M46R0 | 0.68uH | - | 0.0016Ω | 4600mA | - | ||
| FAHPI1250-R82M39R0 | 0.82uH | - | 0.0017Ω | 3900mA | - | ||
| FAHPI1260 | 4.70-150.00uH | - | 0.009-0.35Ω | 2700-24000mA | - | - | - |
| FAHPI1260-4R7M24R0 | 4.70uH | - | 0.0090Ω | 24000mA | - | ||
| FAHPI1260-5R6M22R5 | 5.60uH | - | 0.0110Ω | 22500mA | - | ||
| FAHPI1260-6R8M19R0 | 6.80uH | - | 0.0135Ω | 19000mA | - | ||
| FAHPI1260-8R2M13R5 | 8.20uH | - | 0.0160Ω | 13500mA | - | ||
| FAHPI1260-100M12R5 | 10.00uH | - | 0.0207Ω | 12500mA | - | ||
| FAHPI1260-101M3R5 | 100.00uH | - | 0.2000Ω | 3500mA | - | ||
| FAHPI1260-120M10R0 | 12.00uH | - | 0.0230Ω | 10000mA | - | ||
| FAHPI1260-121M3R2 | 120.00uH | - | 0.2350Ω | 3200mA | - | ||
| FAHPI1260-150M9R0 | 15.00uH | - | 0.0290Ω | 9000mA | - | ||
| FAHPI1260-151M2R7 | 150.00uH | - | 0.3500Ω | 2700mA | - | ||
| FAHPI1260-180M8R0 | 18.00uH | - | 0.0350Ω | 8000mA | - | ||
| FAHPI1260-220M7R5 | 22.00uH | - | 0.0395Ω | 7500mA | - | ||
| FAHPI1260-270M6R5 | 27.00uH | - | 0.0560Ω | 6500mA | - | ||
| FAHPI1260-330M6R0 | 33.00uH | - | 0.0750Ω | 6000mA | - | ||
| FAHPI1260-470M5R5 | 47.00uH | - | 0.0900Ω | 5500mA | - | ||
| FAHPI1260-680M4R5 | 68.00uH | - | 0.1400Ω | 4500mA | - | ||
| FAHPI1265 | 4.70-100.00uH | - | 0.0085-0.17Ω | 4000-24000mA | - | - | - |
| FAHPI1265-4R7M24R0 | 4.70uH | - | 0.0085Ω | 24000mA | - | ||
| FAHPI1265-5R6M22R5 | 5.60uH | - | 0.0105Ω | 22500mA | - | ||
| FAHPI1265-6R8M19R0 | 6.80uH | - | 0.0120Ω | 19000mA | - | ||
| FAHPI1265-8R2M16R0 | 8.20uH | - | 0.0140Ω | 16000mA | - | ||
| FAHPI1265-100M15R0 | 10.00uH | - | 0.0165Ω | 15000mA | - | ||
| FAHPI1265-101M4R0 | 100.00uH | - | 0.1700Ω | 4000mA | - | ||
| FAHPI1265-150M11R0 | 15.00uH | - | 0.0260Ω | 11000mA | - | ||
| FAHPI1265-220M9R0 | 22.00uH | - | 0.0360Ω | 9000mA | - | ||
| FAHPI1265-330M8R0 | 33.00uH | - | 0.0650Ω | 8000mA | - | ||
| FAHPI1265-470M6R8 | 47.00uH | - | 0.0700Ω | 6800mA | - | ||
| FAHPI1265-680M5R2 | 68.00uH | - | 0.1200Ω | 5200mA | - | ||
| FAHPI1265-820M4R5 | 82.00uH | - | 0.1350Ω | 4500mA | - | ||
| FAHPI1770 | 2.20-100.00uH | - | 0.0025-0.1300Ω | 6500-34000mA | - | - | - |
| FAHPI1770-2R2M34R0 | 2.20uH | - | 0.0025Ω | 34000mA | - | ||
| FAHPI1770-3R3M30R0 | 3.30uH | - | 0.0039Ω | 30000mA | - | ||
| FAHPI1770-4R7M24R0 | 4.70uH | - | 0.0048Ω | 24000mA | - | ||
| FAHPI1770-6R8M22R0 | 6.80uH | - | 0.0075Ω | 22000mA | - | ||
| FAHPI1770-8R2M20R0 | 8.20uH | - | 0.0087Ω | 20000mA | - | ||
| FAHPI1770-100M19R0 | 10.00uH | - | 0.0099Ω | 19000mA | - | ||
| FAHPI1770-101M5R0 | 100.00uH | - | 0.1300Ω | 5000mA | - | ||
| FAHPI1770-150M14R5 | 15.00uH | - | 0.0170Ω | 14500mA | - | ||
| FAHPI1770-220M11R5 | 22.00uH | - | 0.0230Ω | 11500mA | - | ||
| FAHPI1770-330M10R0 | 33.00uH | - | 0.0370Ω | 10000mA | - | ||
| FAHPI1770-470M7R5 | 47.00uH | - | 0.0470Ω | 7500mA | - | ||
| FAHPI1770-680M6R5 | 68.00uH | - | 0.0850Ω | 6500mA | - | ||
| FALQH-1210 | 0.1-560uH | - | 0.25-28.0Ω | 40-700mA | - | - | - |
| FALQH-1210-1R0M | 1.00uH | - | 0.5000Ω | 445mA | - | ||
| FALQH-1210-1R2M | 1.20uH | - | 0.6000Ω | 425mA | - | ||
| FALQH-1210-1R5M | 1.50uH | - | 0.6000Ω | 400mA | - | ||
| FALQH-1210-1R8M | 1.80uH | - | 0.7000Ω | 390mA | - | ||
| FALQH-1210-2R2M | 2.20uH | - | 0.8000Ω | 370mA | - | ||
| FALQH-1210-2R7M | 2.70uH | - | 0.9000Ω | 320mA | - | ||
| FALQH-1210-3R3M | 3.30uH | - | 1.0000Ω | 300mA | - | ||
| FALQH-1210-3R9M | 3.90uH | - | 1.1000Ω | 290mA | - | ||
| FALQH-1210-4R7K | 4.70uH | - | 1.2000Ω | 270mA | - | ||
| FALQH-1210-5R6K | 5.60uH | - | 1.3000Ω | 250mA | - | ||
| FALQH-1210-6R8K | 6.80uH | - | 1.5000Ω | 240mA | - | ||
| FALQH-1210-8R2K | 8.20uH | - | 1.6000Ω | 225mA | - | ||
| FALQH-1210-100K | 10.00uH | - | 1.8000Ω | 190mA | - | ||
| FALQH-1210-101K | 100.00uH | - | 7.0000Ω | 80mA | - | ||
| FALQH-1210-120K | 12.00uH | - | 2.0000Ω | 180mA | - | ||
| FALQH-1210-121K | 120.00uH | - | 8.0000Ω | 75mA | - | ||
| FALQH-1210-150K | 15.00uH | - | 2.2000Ω | 170mA | - | ||
| FALQH-1210-151K | 150.00uH | - | 9.3000Ω | 70mA | - | ||
| FALQH-1210-180K | 18.00uH | - | 2.5000Ω | 165mA | - | ||
| FALQH-1210-181K | 180.00uH | - | 10.2000Ω | 65mA | - | ||
| FALQH-1210-220K | 22.00uH | - | 2.8000Ω | 150mA | - | ||
| FALQH-1210-221K | 220.00uH | - | 11.8000Ω | 65mA | - | ||
| FALQH-1210-270K | 27.00uH | - | 3.1000Ω | 125mA | - | ||
| FALQH-1210-271K | 270.00uH | - | 12.5000Ω | 65mA | - | ||
| FALQH-1210-330K | 33.00uH | - | 3.5000Ω | 115mA | - | ||
| FALQH-1210-331K | 330.00uH | - | 13.0000Ω | 65mA | - | ||
| FALQH-1210-390K | 39.00uH | - | 3.9000Ω | 110mA | - | ||
| FALQH-1210-391K | 390.00uH | - | 22.0000Ω | 50mA | - | ||
| FALQH-1210-470K | 47.00uH | - | 4.3000Ω | 100mA | - | ||
| FALQH-1210-471K | 470.00uH | - | 24.7000Ω | 45mA | - | ||
| FALQH-1210-560K | 56.00uH | - | 4.9000Ω | 85mA | - | ||
| FALQH-1210-561K | 560.00uH | - | 28.0000Ω | 40mA | - | ||
| FALQH-1210-680K | 68.00uH | - | 5.5000Ω | 80mA | - | ||
| FALQH-1210-820K | 82.00uH | - | 6.2000Ω | 70mA | - | ||
| FALQH-1210-R10M | 0.10uH | - | 0.2500Ω | 700mA | - | ||
| FALQH-1210-R18M | 0.18uH | - | 0.2500Ω | 650mA | - | ||
| FALQH-1210-R27M | 0.27uH | - | 0.2500Ω | 600mA | - | ||
| FALQH-1210-R39M | 0.39uH | - | 0.2500Ω | 530mA | - | ||
| FALQH-1210-R56M | 0.56uH | - | 0.2500Ω | 530mA | - | ||
| FALQH-1210-R68M | 0.68uH | - | 0.2500Ω | 470mA | - | ||
| FALQH-1210-R82M | 0.82uH | - | 0.2500Ω | 450mA | - | ||
| FALQH-1812 | 1.0-2200uH | - | 0.00094-30Ω | 30-550mA | - | - | - |
| FALQH-1812-1R0M | 1.00uH | - | 0.2000Ω | 550mA | - | ||
| FALQH-1812-1R2M | 1.20uH | - | 0.2500Ω | 530mA | - | ||
| FALQH-1812-1R5M | 1.50uH | - | 0.2800Ω | 500mA | - | ||
| FALQH-1812-1R8M | 1.80uH | - | 0.3000Ω | 500mA | - | ||
| FALQH-1812-2R2M | 2.20uH | - | 0.3000Ω | 500mA | - | ||
| FALQH-1812-2R7M | 2.70uH | - | 0.3200Ω | 500mA | - | ||
| FALQH-1812-3R3M | 3.30uH | - | 0.3500Ω | 500mA | - | ||
| FALQH-1812-3R9M | 3.90uH | - | 0.3800Ω | 500mA | - | ||
| FALQH-1812-4R7K | 4.70uH | - | 0.4000Ω | 500mA | - | ||
| FALQH-1812-5R6K | 5.60uH | - | 0.4700Ω | 500mA | - | ||
| FALQH-1812-6R8K | 6.80uH | - | 0.5000Ω | 500mA | - | ||
| FALQH-1812-8R2K | 8.20uH | - | 0.5600Ω | 500mA | - | ||
| FALQH-1812-100K | 10.00uH | - | 0.5600Ω | 450mA | - | ||
| FALQH-1812-101K | 100.00uH | - | 2.5000Ω | 175mA | - | ||
| FALQH-1812-102K | 1000.00uH | - | 25.000Ω | 50mA | - | ||
| FALQH-1812-120K | 12.00uH | - | 0.6200Ω | 450mA | - | ||
| FALQH-1812-121K | 120.00uH | - | 3.0000Ω | 165mA | - | ||
| FALQH-1812-122K | 1200.00uH | - | 30.0000Ω | 45mA | - | ||
| FALQH-1812-150K | 15.00uH | - | 0.7300Ω | 390mA | - | ||
| FALQH-1812-152K | 1500.00uH | - | 0.0370Ω | 40mA | - | ||
| FALQH-1812-180K | 18.00uH | - | 0.0082Ω | 370mA | - | ||
| FALQH-1812-181K | 180.00uH | - | 0.0045Ω | 135mA | - | ||
| FALQH-1812-182K | 180.00uH | - | 0.0450Ω | 35mA | - | ||
| FALQH-1812-220K | 22.00uH | - | 0.00094Ω | 350mA | - | ||
| FALQH-1812-221K | 220.00uH | - | 0.0054Ω | 125mA | - | ||
| FALQH-1812-222K | 2200.00uH | - | 0.0500Ω | 30mA | - | ||
| FALQH-1812-270K | 27.00uH | - | 0.0011Ω | 330mA | - | ||
| FALQH-1812-271K | 270.00uH | - | 0.0068Ω | 115mA | - | ||
| FALQH-1812-330K | 33.00uH | - | 0.0012Ω | 310mA | - | ||
| FALQH-1812-331K | 330.00uH | - | 0.0082Ω | 100mA | - | ||
| FALQH-1812-390K | 39.00uH | - | 0.0014Ω | 280mA | - | ||
| FALQH-1812-391K | 390.00uH | - | 0.0097Ω | 90mA | - | ||
| FALQH-1812-470K | 47.00uH | - | 0.0015Ω | 250mA | - | ||
| FALQH-1812-471K | 470.00uH | - | 0.0120Ω | 80mA | - | ||
| FALQH-1812-560K | 56.00uH | - | 0.0017Ω | 225mA | - | ||
| FALQH-1812-561K | 560.00uH | - | 0.0150Ω | 70mA | - | ||
| FALQH-1812-680K | 68.00uH | - | 0.0019Ω | 225mA | - | ||
| FALQH-1812-681K | 680.00uH | - | 0.0170Ω | 65mA | - | ||
| FALQH-1812-820K | 82.00uH | - | 0.0022Ω | 185mA | - | ||
| FALQH-1812-821K | 820.00uH | - | 0.0210Ω | 60mA | - | ||
| FALQH-2220 | 0.12-10000uH | - | 0.0100-140.0000Ω | 50-6000mA | - | - | - |
| FALQH-2220-1R0M | 1.00uH | - | 0.0270Ω | 4000mA | - | ||
| FALQH-2220-1R5M | 1.50uH | - | 0.0310Ω | 3700mA | - | ||
| FALQH-2220-2R2M | 2.20uH | - | 0.0410Ω | 3200mA | - | ||
| FALQH-2220-3R3M | 3.30uH | - | 0.0500Ω | 2900mA | - | ||
| FALQH-2220-4R7M | 4.70uH | - | 0.0570Ω | 2700mA | - | ||
| FALQH-2220-6R8M | 6.80uH | - | 0.1000Ω | 2000mA | - | ||
| FALQH-2220-100K | 10.00uH | - | 0.1300Ω | 1700mA | - | ||
| FALQH-2220-101K | 100.00uH | - | 1.2000Ω | 560mA | - | ||
| FALQH-2220-102K | 1000.00uH | - | 14.4000Ω | 150mA | - | ||
| FALQH-2220-103K | 10000.00uH | - | 140.0000Ω | 50mA | - | ||
| FALQH-2220-150K | 15.00uH | - | 0.2100Ω | 1400mA | - | ||
| FALQH-2220-151K | 150.00uH | - | 2.6600Ω | 420mA | - | ||
| FALQH-2220-152K | 1500.00uH | - | 30.1000Ω | 100mA | - | ||
| FALQH-2220-220K | 22.00uH | - | 0.2700Ω | 1200mA | - | ||
| FALQH-2220-221K | 220.00uH | - | 3.3600Ω | 320mA | - | ||
| FALQH-2220-222K | 2200.00uH | - | 45.0000Ω | 90mA | - | ||
| FALQH-2220-330K | 33.00uH | - | 0.4500Ω | 900mA | - | ||
| FALQH-2220-331K | 330.00uH | - | 6.1600Ω | 270mA | - | ||
| FALQH-2220-332K | 3300.00uH | - | 50.0000Ω | 80mA | - | ||
| FALQH-2220-470K | 47.00uH | - | 0.5600Ω | 800mA | - | ||
| FALQH-2220-471K | 470.00uH | - | 7.5600Ω | 240mA | - | ||
| FALQH-2220-472K | 4700.00uH | - | 61.0000Ω | 70mA | - | ||
| FALQH-2220-680K | 68.00uH | - | 0.9400Ω | 640mA | - | ||
| FALQH-2220-681K | 680.00uH | - | 11.3000Ω | 190mA | - | ||
| FALQH-2220-682K | 6800.00uH | - | 100.0000Ω | 60mA | - | ||
| FALQH-2220-822K | 8200.00uH | - | 125.0000Ω | 50mA | - | ||
| FALQH-2220-R12M | 0.12uH | - | 0.0100Ω | 6000mA | - | ||
| FALQH-2220-R27M | 0.27uH | - | 0.0140Ω | 5300mA | - | ||
| FALQH-2220-R47M | 0.47uH | - | 0.0180Ω | 4800mA | - | ||
| FAMPI0412 | 0.10-10.0uH | - | 0.0055-0.4630Ω | 1400-25000mA | - | - | - |
| FAMPI0412-1R0M6R0 | 1.00uH | - | 0.0500Ω | 6000mA | - | ||
| FAMPI0412-1R5M4R0 | 1.50uH | - | 0.0730Ω | 4000mA | - | ||
| FAMPI0412-2R2M3R5 | 2.20uH | - | 0.0800Ω | 3500mA | - | ||
| FAMPI0412-3R3M3R0 | 3.30uH | - | 0.0970Ω | 3000mA | - | ||
| FAMPI0412-4R7M2R5 | 4.70uH | - | 0.1850Ω | 2500mA | - | ||
| FAMPI0412-5R6M2R3 | 5.60uH | - | 0.2080Ω | 2300mA | - | ||
| FAMPI0412-6R8M1R7 | 6.80uH | - | 0.3600Ω | 1700mA | - | ||
| FAMPI0412-8R2M1R6 | 8.20uH | - | 0.3760Ω | 1600mA | - | ||
| FAMPI0412-100M1R4 | 10.00uH | - | 0.4630Ω | 1400mA | - | ||
| FAMPI0412-R10M25R0 | 0.10uH | - | 0.0055Ω | 25000mA | - | ||
| FAMPI0412-R22M20R0 | 0.22uH | - | 0.0120Ω | 20000mA | - | ||
| FAMPI0412-R47M6R5 | 0.47uH | - | 0.0200Ω | 6500mA | - | ||
| FAMPI0420 | 0.10-22.0uH | - | 0.004-0.500Ω | 1400-35000mA | - | - | - |
| FAMPI0420-1R0M8R5 | 1.00uH | - | 0.0275Ω | 8500mA | - | ||
| FAMPI0420-1R2M7R8 | 1.20uH | - | 0.0300Ω | 7800mA | - | ||
| FAMPI0420-1R5M7R0 | 1.50uH | - | 0.0420Ω | 7000mA | - | ||
| FAMPI0420-2R2M6R0 | 2.20uH | - | 0.0610Ω | 6000mA | - | ||
| FAMPI0420-3R3M4R0 | 3.30uH | - | 0.0900Ω | 4000mA | - | ||
| FAMPI0420-4R7M3R5 | 4.70uH | - | 0.1050Ω | 3500mA | - | ||
| FAMPI0420-5R6M3R0 | 5.60uH | - | 0.1250Ω | 3000mA | - | ||
| FAMPI0420-6R8M2R8 | 6.80uH | - | 0.1720Ω | 2800mA | - | ||
| FAMPI0420-8R2M2R5 | 8.20uH | - | 0.1800Ω | 2500mA | - | ||
| FAMPI0420-100M2R3 | 10.00uH | - | 0.2430Ω | 2300mA | - | ||
| FAMPI0420-150M1R9 | 15.00uH | - | 0.3740Ω | 1900mA | - | ||
| FAMPI0420-220M1R4 | 22.00uH | - | 0.5000Ω | 1400mA | - | ||
| FAMPI0420-R10M35R0 | 0.10uH | - | 0.0040Ω | 35000mA | - | ||
| FAMPI0420-R18M28R0 | 0.18uH | - | 0.0054Ω | 28000mA | - | ||
| FAMPI0420-R22M24R0 | 0.22uH | - | 0.0073Ω | 24000mA | - | ||
| FAMPI0420-R33M18R0 | 0.33uH | - | 0.0086Ω | 18000mA | - | ||
| FAMPI0420-R47M12R0 | 0.47uH | - | 0.0140Ω | 12000mA | - | ||
| FAMPI0420-R56M10R0 | 0.56uH | - | 0.0170Ω | 10000mA | - | ||
| FAMPI0420-R68M10R0 | 0.68uH | - | 0.0190Ω | 10000mA | - | ||
| FAMPI0512 | 0.10-10.0uH | - | 0.0052-0.385Ω | 1800-14500mA | - | - | - |
| FAMPI0512-1R0M6R0 | 1.00uH | - | 0.0300Ω | 6000mA | - | ||
| FAMPI0512-1R2M5R5 | 1.20uH | - | 0.0400Ω | 5500mA | - | ||
| FAMPI0512-1R5M5R0 | 1.50uH | - | 0.0440Ω | 5000mA | - | ||
| FAMPI0512-2R2M4R0 | 2.20uH | - | 0.0750Ω | 4000mA | - | ||
| FAMPI0512-3R3M3R8 | 3.30uH | - | 0.0860Ω | 3800mA | - | ||
| FAMPI0512-4R7M3R2 | 4.70uH | - | 0.1150Ω | 3200mA | - | ||
| FAMPI0512-5R6M3R2 | 5.60uH | - | 0.2010Ω | 3200mA | - | ||
| FAMPI0512-6R8M3R0 | 6.80uH | - | 0.2220Ω | 3000mA | - | ||
| FAMPI0512-8R2M2R8 | 8.20uH | - | 0.3780Ω | 2800mA | - | ||
| FAMPI0512-100M1R8 | 10.00uH | - | 0.3850Ω | 1800mA | - | ||
| FAMPI0512-R10M14R5 | 0.10uH | - | 0.0052Ω | 14500mA | - | ||
| FAMPI0512-R22M14R0 | 0.22uH | - | 0.0067Ω | 14000mA | - | ||
| FAMPI0512-R33M13R5 | 0.33uH | - | 0.0094Ω | 13500mA | - | ||
| FAMPI0512-R36M13R0 | 0.36uH | - | 0.0115Ω | 13000mA | - | ||
| FAMPI0512-R47M11R0 | 0.47uH | - | 0.0158Ω | 11000mA | - | ||
| FAMPI0512-R68M9R0 | 0.68uH | - | 0.0245Ω | 9000mA | - | ||
| FAMPI0515 | 0.33-10.0uH | - | 0.0098-0.2350Ω | 2300-16000mA | - | - | - |
| FAMPI0515-1R0M9R0 | 1.00uH | - | 0.0253Ω | 9000mA | - | ||
| FAMPI0515-1R5M7R0 | 1.50uH | - | 0.0450Ω | 7000mA | - | ||
| FAMPI0515-2R2M6R0 | 2.20uH | - | 0.0520Ω | 6000mA | - | ||
| FAMPI0515-3R3M4R5 | 3.30uH | - | 0.0900Ω | 4500mA | - | ||
| FAMPI0515-4R7M4R0 | 4.70uH | - | 0.1180Ω | 4000mA | - | ||
| FAMPI0515-5R6M3R2 | 5.60uH | - | 0.1520Ω | 3200mA | - | ||
| FAMPI0515-6R8M3R0 | 6.80uH | - | 0.1710Ω | 3000mA | - | ||
| FAMPI0515-8R2M2R6 | 8.20uH | - | 0.2100Ω | 2600mA | - | ||
| FAMPI0515-100M2R3 | 10.00uH | - | 0.2350Ω | 2300mA | - | ||
| FAMPI0515-R33M16R0 | 0.33uH | - | 0.0098Ω | 16000mA | - | ||
| FAMPI0515-R47M15R0 | 0.47uH | - | 0.0138Ω | 15000mA | - | ||
| FAMPI0515-R68M13R0 | 0.68uH | - | 0.0162Ω | 13000mA | - | ||
| FAMPI0518 | 0.33-10.0uH | - | 0.0086-0.1900Ω | 2800-15000mA | - | - | - |
| FAMPI0518-1R0M10R0 | 1.00uH | - | 0.0210Ω | 10000mA | - | ||
| FAMPI0518-1R5M9R0 | 1.50uH | - | 0.0300Ω | 9000mA | - | ||
| FAMPI0518-2R2M7R5 | 2.20uH | - | 0.0483Ω | 7500mA | - | ||
| FAMPI0518-3R3M5R0 | 3.30uH | - | 0.0690Ω | 5000mA | - | ||
| FAMPI0518-4R7M4R5 | 4.70uH | - | 0.0980Ω | 4500mA | - | ||
| FAMPI0518-5R6M4R0 | 5.60uH | - | 0.1270Ω | 4000mA | - | ||
| FAMPI0518-6R8M3R5 | 6.80uH | - | 0.1370Ω | 3500mA | - | ||
| FAMPI0518-8R2M3R0 | 8.20uH | - | 0.1650Ω | 3000mA | - | ||
| FAMPI0518-100M2R8 | 10.00uH | - | 0.1900Ω | 2800mA | - | ||
| FAMPI0518-R33M15R0 | 0.33uH | - | 0.0086Ω | 15000mA | - | ||
| FAMPI0518-R47M14R0 | 0.47uH | - | 0.0113Ω | 14000mA | - | ||
| FAMPI0518-R68M13R0 | 0.68uH | - | 0.0143Ω | 13000mA | - | ||
| FAMPI0520 | 0.33-10.00uH | - | 0.0073-0.1890Ω | 3400-21300mA | - | - | - |
| FAMPI0520-1R0M11R7 | 1.00uH | - | 0.0192Ω | 11700mA | - | ||
| FAMPI0520-1R2M11R0 | 1.20uH | - | 0.0280Ω | 11000mA | - | ||
| FAMPI0520-1R5M9R8 | 1.50uH | - | 0.0305Ω | 9800mA | - | ||
| FAMPI0520-2R2M9R0 | 2.20uH | - | 0.0500Ω | 9000mA | - | ||
| FAMPI0520-3R3M7R3 | 3.30uH | - | 0.0700Ω | 7300mA | - | ||
| FAMPI0520-4R7M5R0 | 4.70uH | - | 0.1060Ω | 5000mA | - | ||
| FAMPI0520-5R6M4R0 | 5.60uH | - | 0.1220Ω | 4000mA | - | ||
| FAMPI0520-6R8M3R8 | 6.80uH | - | 0.1450Ω | 3800mA | - | ||
| FAMPI0520-8R2M3R5 | 8.20uH | - | 0.1680Ω | 3500mA | - | ||
| FAMPI0520-100M3R4 | 10.00uH | - | 0.1890Ω | 3400mA | - | ||
| FAMPI0520-R33M21R3 | 0.33uH | - | 0.0073Ω | 21300mA | - | ||
| FAMPI0520-R47M18R0 | 0.47uH | - | 0.0086Ω | 18000mA | - | ||
| FAMPI0520-R68M12R8 | 0.68uH | - | 0.01240Ω | 12800mA | - | ||
| FAMPI0530 | 0.33-10.00uH | - | 0.0050-0.1260Ω | 3500-18000mA | - | - | - |
| FAMPI0530-1R0M11R0 | 1.00uH | - | 0.0135Ω | 11000mA | - | ||
| FAMPI0530-1R2M11R0 | 1.20uH | - | 0.0155Ω | 11000mA | - | ||
| FAMPI0530-1R5M10R0 | 1.50uH | - | 0.0230Ω | 10000mA | - | ||
| FAMPI0530-2R2M9R0 | 2.20uH | - | 0.0350Ω | 9000mA | - | ||
| FAMPI0530-3R3M8R0 | 3.30uH | - | 0.0380Ω | 8000mA | - | ||
| FAMPI0530-4R7M6R0 | 4.70uH | - | 0.0530Ω | 6000mA | - | ||
| FAMPI0530-5R6M6R0 | 5.60uH | - | 0.0630Ω | 6000mA | - | ||
| FAMPI0530-6R8M4R3 | 6.80uH | - | 0.0762Ω | 4300mA | - | ||
| FAMPI0530-100M3R5 | 10.00uH | - | 0.1260Ω | 3500mA | - | ||
| FAMPI0530-R33M18R0 | 0.33uH | - | 0.0050Ω | 18000mA | - | ||
| FAMPI0530-R47M16R0 | 0.47uH | - | 0.0074Ω | 16000mA | - | ||
| FAMPI0530-R68M14R0 | 0.68uH | - | 0.0115Ω | 14000mA | - | ||
| FAMPI0612 | 0.22-10.00uH | - | 0.0075-0.2900Ω | 2500-19000mA | - | - | - |
| FAMPI0612-1R0M7R0 | 1.00uH | - | 0.0300Ω | 7000mA | - | ||
| FAMPI0612-1R2M6R8 | 1.20uH | - | 0.0360Ω | 6800mA | - | ||
| FAMPI0612-1R5M6R5 | 1.50uH | - | 0.0400Ω | 6500mA | - | ||
| FAMPI0612-2R2M5R0 | 2.20uH | - | 0.0610Ω | 5000mA | - | ||
| FAMPI0612-3R3M4R0 | 3.30uH | - | 0.1000Ω | 4000mA | - | ||
| FAMPI0612-4R7M3R8 | 4.70uH | - | 0.1500Ω | 3800mA | - | ||
| FAMPI0612-6R8M3R0 | 6.80uH | - | 0.1980Ω | 3000mA | - | ||
| FAMPI0612-100M2R5 | 10.00uH | - | 0.2900Ω | 2500mA | - | ||
| FAMPI0612-R22M19R0 | 0.22uH | - | 0.0075Ω | 19000mA | - | ||
| FAMPI0612-R33M16R0 | 0.33uH | - | 0.0100Ω | 16000mA | - | ||
| FAMPI0612-R47M12R0 | 0.47uH | - | 0.0170Ω | 12000mA | - | ||
| FAMPI0612-R68M9R0 | 0.68uH | - | 0.0190Ω | 9000mA | - | ||
| FAMPI0615 | 0.22-10.00uH | - | 0.0052-0.2160Ω | 2800-22000mA | - | - | - |
| FAMPI0615-1R0M12R0 | 1.00uH | - | 0.0258Ω | 12000mA | - | ||
| FAMPI0615-1R2M10R5 | 1.20uH | - | 0.0340Ω | 10500mA | - | ||
| FAMPI0615-1R5M9R5 | 1.50uH | - | 0.0425Ω | 9500mA | - | ||
| FAMPI0615-2R2M6R5 | 2.20uH | - | 0.0540Ω | 6500mA | - | ||
| FAMPI0615-3R3M6R0 | 3.30uH | - | 0.0700Ω | 6000mA | - | ||
| FAMPI0615-4R7M5R0 | 4.70uH | - | 0.1080Ω | 5000mA | - | ||
| FAMPI0615-5R6M4R5 | 5.60uH | - | 0.1380Ω | 4500mA | - | ||
| FAMPI0615-6R8M3R5 | 6.80uH | - | 0.1460Ω | 3500mA | - | ||
| FAMPI0615-8R2M3R2 | 8.20uH | - | 0.1840Ω | 3200mA | - | ||
| FAMPI0615-100M2R8 | 10.00uH | - | 0.2160Ω | 2800mA | - | ||
| FAMPI0615-R22M22R0 | 0.22uH | - | 0.0052Ω | 22000mA | - | ||
| FAMPI0615-R33M18R0 | 0.33uH | - | 0.0076Ω | 18000mA | - | ||
| FAMPI0615-R47M16R0 | 0.47uH | - | 0.0103Ω | 16000mA | - | ||
| FAMPI0615-R68M15R0 | 0.68uH | - | 0.0152Ω | 15000mA | - | ||
| FAMPI0618 | 0.33-10.00uH | - | 0.0058-0.1600Ω | 3500-22000mA | - | - | - |
| FAMPI0618-1R0M14R0 | 1.00uH | - | 0.0170Ω | 14000mA | - | ||
| FAMPI0618-1R2M13R5 | 1.20uH | - | 0.0240Ω | 13500mA | - | ||
| FAMPI0618-1R5M13R0 | 1.50uH | - | 0.0252Ω | 13000mA | - | ||
| FAMPI0618-2R2M11R0 | 2.20uH | - | 0.0350Ω | 11000mA | - | ||
| FAMPI0618-3R3M9R0 | 3.30uH | - | 0.0460Ω | 9000mA | - | ||
| FAMPI0618-4R7M7R0 | 4.70uH | - | 0.0760Ω | 7000mA | - | ||
| FAMPI0618-5R6M6R0 | 5.60uH | - | 0.0860Ω | 6000mA | - | ||
| FAMPI0618-6R8M5R5 | 6.80uH | - | 0.1040Ω | 5500mA | - | ||
| FAMPI0618-8R2M4R5 | 8.20uH | - | 0.1400Ω | 4500mA | - | ||
| FAMPI0618-100M3R5 | 10.00uH | - | 0.1600Ω | 3500mA | - | ||
| FAMPI0618-R33M22R0 | 0.33uH | - | 0.0058Ω | 22000mA | - | ||
| FAMPI0618-R47M18R0 | 0.47uH | - | 0.0074Ω | 18000mA | - | ||
| FAMPI0618-R68M17R0 | 0.68uH | - | 0.0110Ω | 17000mA | - | ||
| FAMPI0618-R82M15R5 | 0.82uH | - | 0.0140Ω | 15500mA | - | ||
| FAMPI0620 | 0.10-22.0uH | - | 0.0024-0.28Ω | 2500-40000mA | - | - | - |
| FAMPI0620-1R0M14R0 | 1.00uH | - | 0.0165Ω | 14000mA | - | ||
| FAMPI0620-1R5M12R0 | 1.50uH | - | 0.0245Ω | 12000mA | - | ||
| FAMPI0620-2R2M10R0 | 2.20uH | - | 0.0340Ω | 10000mA | - | ||
| FAMPI0620-3R3M8R0 | 3.30uH | - | 0.0480Ω | 8000mA | - | ||
| FAMPI0620-4R7M7R0 | 4.70uH | - | 0.0595Ω | 7000mA | - | ||
| FAMPI0620-5R6M6R0 | 5.60uH | - | 0.0680Ω | 6000mA | - | ||
| FAMPI0620-6R8M5R5 | 6.80uH | - | 0.0730Ω | 5500mA | - | ||
| FAMPI0620-8R2M5R0 | 8.20uH | - | 0.1160Ω | 5000mA | - | ||
| FAMPI0620-100M4R0 | 10.00uH | - | 0.1540Ω | 4000mA | - | ||
| FAMPI0620-220M2R5 | 22.00uH | - | 0.2800Ω | 2500mA | - | ||
| FAMPI0620-R10M40R0 | 0.10uH | - | 0.0024Ω | 40000mA | - | ||
| FAMPI0620-R20M35R0 | 0.20uH | - | 0.0030Ω | 35000mA | - | ||
| FAMPI0620-R33M25R0 | 0.33uH | - | 0.0050Ω | 25000mA | - | ||
| FAMPI0620-R47M20R0 | 0.47uH | - | 0.0083Ω | 20000mA | - | ||
| FAMPI0620-R68M16R0 | 0.68uH | - | 0.0100Ω | 16000mA | - | ||
| FAMPI0624 | 0.10-22.0uH | - | 0.0017-0.215Ω | 3000-70000mA | - | - | - |
| FAMPI0624-1R0M16R0 | 1.00uH | - | 0.0135Ω | 16000mA | - | ||
| FAMPI0624-1R5M15R0 | 1.50uH | - | 0.0207Ω | 15000mA | - | ||
| FAMPI0624-2R2M14R0 | 2.20uH | - | 0.0275Ω | 14000mA | - | ||
| FAMPI0624-3R3M10R0 | 3.30uH | - | 0.0378Ω | 10000mA | - | ||
| FAMPI0624-4R7M9R0 | 4.70uH | - | 0.0500Ω | 9000mA | - | ||
| FAMPI0624-5R6M8R0 | 5.60uH | - | 0.0620Ω | 8000mA | - | ||
| FAMPI0624-6R8M7R0 | 6.80uH | - | 0.0705Ω | 7000mA | - | ||
| FAMPI0624-8R2M6R0 | 8.20uH | - | 0.0950Ω | 6000mA | - | ||
| FAMPI0624-100M5R0 | 10.00uH | - | 0.1010Ω | 5000mA | - | ||
| FAMPI0624-220M3R0 | 22.00uH | - | 0.2150Ω | 3000mA | - | ||
| FAMPI0624-R10M70R0 | 0.10uH | - | 0.0017Ω | 70000mA | - | ||
| FAMPI0624-R15M45R0 | 0.15uH | - | 0.0023Ω | 45000mA | - | ||
| FAMPI0624-R20M40R0 | 0.20uH | - | 0.0028Ω | 40000mA | - | ||
| FAMPI0624-R22M34R0 | 0.22uH | - | 0.0032Ω | 34000mA | - | ||
| FAMPI0624-R33M30R0 | 0.33uH | - | 0.0044Ω | 30000mA | - | ||
| FAMPI0624-R36M29R0 | 0.36uH | - | 0.0046Ω | 29000mA | - | ||
| FAMPI0624-R47M26R0 | 0.47uH | - | 0.0055Ω | 26000mA | - | ||
| FAMPI0624-R56M24R0 | 0.56uH | - | 0.0068Ω | 24000mA | - | ||
| FAMPI0624-R60M22R0 | 0.60uH | - | 0.0069Ω | 22000mA | - | ||
| FAMPI0624-R68M21R0 | 0.68uH | - | 0.072Ω | 21000mA | - | ||
| FAMPI0624-R82M17R0 | 0.82uH | - | 0.0095Ω | 17000mA | - | ||
| FAMPI0630 | 0.22-22.0uH | - | 0.0028-0.186Ω | 3500-40000mA | - | - | - |
| FAMPI0630-1R0M22R0 | 1.00uH | - | 0.0095Ω | 22000mA | - | ||
| FAMPI0630-1R5M18R0 | 1.50uH | - | 0.0150Ω | 18000mA | - | ||
| FAMPI0630-1R8M16R0 | 1.80uH | - | 0.0170Ω | 16000mA | - | ||
| FAMPI0630-2R2M14R0 | 2.20uH | - | 0.0200Ω | 14000mA | - | ||
| FAMPI0630-2R5M13R0 | 2.50uH | - | 0.0220Ω | 13000mA | - | ||
| FAMPI0630-3R3M12R5 | 3.30uH | - | 0.0295Ω | 12500mA | - | ||
| FAMPI0630-4R7M10R0 | 4.70uH | - | 0.0395Ω | 10000mA | - | ||
| FAMPI0630-5R6M9R0 | 5.60uH | - | 0.0475Ω | 9000mA | - | ||
| FAMPI0630-6R8M8R0 | 6.80uH | - | 0.0550Ω | 8000mA | - | ||
| FAMPI0630-8R2M7R5 | 8.20uH | - | 0.0680Ω | 7500mA | - | ||
| FAMPI0630-100M6R0 | 10.00uH | - | 0.0832Ω | 6000mA | - | ||
| FAMPI0630-220M3R5 | 22.00uH | - | 0.1860Ω | 3500mA | - | ||
| FAMPI0630-R22M40R0 | 0.22uH | - | 0.0028Ω | 40000mA | - | ||
| FAMPI0630-R33M32R0 | 0.33uH | - | 0.0039Ω | 32000mA | - | ||
| FAMPI0630-R47M26R0 | 0.47uH | - | 0.0042Ω | 26000mA | - | ||
| FAMPI0630-R56M25R5 | 0.56uH | - | 0.0050Ω | 25500mA | - | ||
| FAMPI0630-R68M25R0 | 0.68uH | - | 0.0055Ω | 25000mA | - | ||
| FAMPI0630-R75M24R5 | 0.75uH | - | 0.0066Ω | 24500mA | - | ||
| FAMPI0630-R82M24R0 | 0.82uH | - | 0.0078Ω | 24000mA | - | ||
| FAMPI0650 | 0.47-22uH | - | 0.0039-0.16Ω | 5500-30000mA | - | - | - |
| FAMPI0650-1R0M20R2 | 1.00uH | - | 0.0065Ω | 20200mA | - | ||
| FAMPI0650-1R2M18R0 | 1.20uH | - | 0.0075Ω | 18000mA | - | ||
| FAMPI0650-1R5M16R5 | 1.50uH | - | 0.0090Ω | 16500mA | - | ||
| FAMPI0650-1R8M15R0 | 1.80uH | - | 0.0110Ω | 15000mA | - | ||
| FAMPI0650-2R2M14R0 | 2.20uH | - | 0.0116Ω | 14000mA | - | ||
| FAMPI0650-3R3M12R0 | 3.30uH | - | 0.0209Ω | 12000mA | - | ||
| FAMPI0650-4R7M10R0 | 4.70uH | - | 0.0302Ω | 10000mA | - | ||
| FAMPI0650-5R6M9R0 | 5.60uH | - | 0.0490Ω | 9000mA | - | ||
| FAMPI0650-6R8M8R5 | 6.80uH | - | 0.0505Ω | 8500mA | - | ||
| FAMPI0650-8R2M8R0 | 8.20uH | - | 0.0600Ω | 8000mA | - | ||
| FAMPI0650-100M7R5 | 10.00uH | - | 0.0690Ω | 7500mA | - | ||
| FAMPI0650-220M5R5 | 22.00uH | - | 0.1600Ω | 5500mA | - | ||
| FAMPI0650-R47M30R0 | 0.47uH | - | 0.0039Ω | 30000mA | - | ||
| FAMPI0650-R56M27R0 | 0.56uH | - | 0.0042Ω | 27000mA | - | ||
| FAMPI0650-R60M25R0 | 0.60uH | - | 0.0043Ω | 25000mA | - | ||
| FAMPI0650-R68M24R0 | 0.68uH | - | 0.0045Ω | 24000mA | - | ||
| FAMPI0650-R82M22R0 | 0.82uH | - | 0.0049Ω | 22000mA | - | ||
| FAMPI1040 | 0.15-5.60uH | - | 0.00065-0.0193Ω | 18000-100000mA | - | - | - |
| FAMPI1040-1R0M41R0 | 1.00uH | - | 0.0032Ω | 41000mA | - | ||
| FAMPI1040-1R5M38R0 | 1.50uH | - | 0.0042Ω | 38000mA | - | ||
| FAMPI1040-2R2M27R0 | 2.20uH | - | 0.0070Ω | 27000mA | - | ||
| FAMPI1040-3R3M25R5 | 3.30uH | - | 0.0118Ω | 25500mA | - | ||
| FAMPI1040-4R7M19R0 | 4.70uH | - | 0.0186Ω | 19000mA | - | ||
| FAMPI1040-5R6M18R0 | 5.60uH | - | 0.0193Ω | 18000mA | - | ||
| FAMPI1040-R15M100R0 | 0.15uH | - | 0.00065Ω | 100000mA | - | ||
| FAMPI1040-R22M90R0 | 0.22uH | - | 0.00095Ω | 90000mA | - | ||
| FAMPI1040-R36M70R0 | 0.36uH | - | 0.00125Ω | 70000mA | - | ||
| FAMPI1040-R56M45R0 | 0.56uH | - | 0.0018Ω | 45000mA | - | ||
| FAMPI1040-R68M43R0 | 0.68uH | - | 0.0021Ω | 43000mA | - | ||
| FAMPI1260 | 1.00-220uH | - | 0.0024-0.55Ω | 3000-45000mA | - | - | - |
| FAMPI1260-1R0M45R0 | 1.00uH | - | 0.0024Ω | 45000mA | - | ||
| FAMPI1260-1R2M44R0 | 1.20uH | - | 0.0045Ω | 44000mA | - | ||
| FAMPI1260-1R5M43R0 | 1.50uH | - | 0.0032Ω | 43000mA | - | ||
| FAMPI1260-2R2M34R0 | 2.20uH | - | 0.0047Ω | 34000mA | - | ||
| FAMPI1260-3R3M28R0 | 3.30uH | - | 0.0071Ω | 28000mA | - | ||
| FAMPI1260-4R7M25R0 | 4.70uH | - | 0.0115Ω | 25000mA | - | ||
| FAMPI1260-5R6M22R0 | 5.60uH | - | 0.0126Ω | 22000mA | - | ||
| FAMPI1260-6R8M19R0 | 6.80uH | - | 0.0138Ω | 19000mA | - | ||
| FAMPI1260-8R2M17R0 | 8.20uH | - | 0.0160Ω | 17000mA | - | ||
| FAMPI1260-100M15R5 | 10.00uH | - | 0.0207Ω | 15500mA | - | ||
| FAMPI1260-101M5R0 | 100.00uH | - | 0.2000Ω | 5000mA | - | ||
| FAMPI1260-120M13R5 | 12.00uH | - | 0.0230Ω | 13500mA | - | ||
| FAMPI1260-121M4R5 | 120.00uH | - | 0.2350Ω | 4500mA | - | ||
| FAMPI1260-150M13R0 | 15.00uH | - | 0.0290Ω | 13000mA | - | ||
| FAMPI1260-151M4R0 | 150.00uH | - | 0.3500Ω | 4000mA | - | ||
| FAMPI1260-180M12R0 | 18.00uH | - | 0.0350Ω | 12000mA | - | ||
| FAMPI1260-220M11R0 | 22.00uH | - | 0.0395Ω | 11000mA | - | ||
| FAMPI1260-221M3R0 | 220.00uH | - | 0.5500Ω | 3000mA | - | ||
| FAMPI1260-270M9R0 | 27.00uH | - |
