AAQ Filter Models: 7 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | PF | Efficiency | Certificate | Spec. | Sample Application |
| AAQ30 Series | 30 | 120-277 | 530-1000 | 25-56 | 0.95 | 85% | CE | - | |
| AAQ30-56-C1000 | 30 | 120-277 | 530-1000 | 25-56 | 0.95 | 85% | CE | ||
| AAQ30-56-C1000-S | 30 | 120-277 | 530-1000 | 25-56 | 0.95 | 85% | CE | ||
| AAQ50 Series | 50 | 120-277 | 700-1660 | 25-72 | 0.95 | 89% | CE | - | |
| AAQ50-56-C1700 | 50 | 120-277 | 890-1660 | 25-56 | 0.95 | 89% | CE | ||
| AAQ50-56-C1700-S | 50 | 120-277 | 890-1660 | 25-56 | 0.95 | 89% | CE | ||
| AAQ50-72-C1050 | 50 | 120-277 | 700-1050 | 36-72 | 0.95 | 89% | CE | ||
| AAQ50-72-C1050-S | 50 | 120-277 | 700-1050 | 36-72 | 0.95 | 89% | CE | ||
| AAQ75 Series | 75 | 120-277 | 500-2100 | 25-108 | 0.95 | 89%-90% | CE | - | |
| AAQ75-56-C2100 | 75 | 120-277 | 900-2100 | 25-56 | 0.95 | 89% | CE | ||
| AAQ75-56-C2100-S | 75 | 120-277 | 900-2100 | 25-56 | 0.95 | 89% | CE | ||
| AAQ75-108-C1050 | 75 | 120-277 | 500-1050 | 54-108 | 0.95 | 90% | CE | ||
| AAQ75-108-C1050-S | 75 | 120-277 | 500-1050 | 54-108 | 0.95 | 90% | CE | ||
| AAQ100 Series | 100 | 120-277 | 500-2800 | 25-143 | 0.97 | 90.5% | CE | - | |
| AAQ100-56-C2800 | 100 | 120-277 | 1300-2800 | 25-56 | 0.97 | 90.5% | CE | ||
| AAQ100-56-C2800-S | 100 | 120-277 | 1300-2800 | 25-56 | 0.97 | 90.5% | CE | ||
| AAQ100-143-C1050 | 100 | 120-277 | 500-1050 | 75-143 | 0.97 | 90.5% | CE | ||
| AAQ100-143-C1050-S | 100 | 120-277 | 500-1050 | 75-143 | 0.97 | 90.5% | CE | ||
| AAQ150 Series | 150 | 120-277 | 700-4170 | 25-214 | 0.97 | 91.5%-93% | CE | - | |
| AAQ150-56-C4170 | 150 | 120-277 | 2670-4170 | 25-56 | 0.97 | 91.5% | CE | ||
| AAQ150-56-C4170-S | 150 | 120-277 | 2670-4170 | 25-56 | 0.97 | 91.5% | CE | ||
| AAQ150-214-C1050 | 150 | 120-277 | 700-1050 | 95-214 | 0.97 | 93% | CE | ||
| AAQ150-214-C1050-S | 150 | 120-277 | 700-1050 | 95-214 | 0.97 | 93% | CE | ||
| AAQ200 Series | 200 | 120-277 | 700-5600 | 25-286 | 0.97 | 92%-93.5% | CE | - | |
| AAQ200-56-C5600 | 200 | 120-277 | 2600-5600 | 25-56 | 0.97 | 92% | CE | ||
| AAQ200-56-C5600-S | 200 | 120-277 | 2600-5600 | 25-56 | 0.97 | 92% | CE | ||
| AAQ200-143-C1050 | 200 | 120-277 | 700-1050 | 143-286 | 0.97 | 93.5% | CE | ||
| AAQ200-143-C1050-S | 200 | 120-277 | 700-1050 | 143-286 | 0.97 | 93.5% | CE | ||
| AAQ240 Series | 240 | 120-277 | 700-6700 | 25-343 | 0.97 | 92%-93.5% | CE | - | |
| AAQ240-56-C6700 | 240 | 120-277 | 4300-6700 | 25-56 | 0.97 | 92% | CE | ||
| AAQ240-56-C6700-S | 240 | 120-277 | 4300-6700 | 25-56 | 0.97 | 92% | CE | ||
| AAQ240-343-C1050 | 240 | 120-277 | 700-1050 | 171-343 | 0.97 | 93.5% | CE | ||
| AAQ240-343-C1050-S | 240 | 120-277 | 700-1050 | 171-343 | 0.97 | 93.5% | CE |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
