AAR

AAR100
AAR150
AAR200
AAR240
AAR320
Click to expand the criteria search box
  • Product number

  • {/php}
  • Rated power(W)

  • Input voltage(V)

  • Output current(mA)

  • Output voltage(V)

AAR Filter Models: 5 in total, please see the table below.

Series Rated power(W) Input voltage(V) Output current(mA) Output voltage(V) PF Efficiency Certificate Spec. Sample Application
AAR100 Series
100 120-277 650-2800 25-56 0.97 90.5% CE
-
AAR100-56-C2800
100 120-277 650-2800 25-56 0.97 90.5% CE
AAR100-56-C2800-S
100 120-277 650-2800 25-56 0.97 90.5% CE
AAR150 Series
150 120-277 1340-4170 25-56 0.97 91% CE
-
AAR150-56-C4170
150 120-277 1340-4170 25-56 0.97 91% CE
AAR200 Series
200 120-277 1390-5550 25-56 0.97 91.5% CE
-
AAR240 Series
240 120-277 4300-6000 25-56 0.97 91.5% CE
-
AAR320 Series
320 120-277 2850-8000 25-56 0.97 93% CE
-

* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
