SAB Filter Models: 2 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output current（mA） | Output voltage（V） | Efficiency | Certificate | Spec. | Sample Application |
| SAB03 Series | 3 | 85-305 | 130-600 | 5-24 | - | UKCA CE | - | |
| SAB03-S05R2 | 3 | 85-305 | 600 | 5 | 70% | UKCA CE | ||
| SAB03-S09R2 | 3 | 85-305 | 330 | 9 | 72% | UKCA CE | ||
| SAB03-S12R2 | 3 | 85-305 | 250 | 12 | 74% | UKCA CE | ||
| SAB03-S15R2 | 3 | 85-305 | 200 | 15 | 76% | UKCA CE | ||
| SAB03-S24R2 | 3 | 85-305 | 130 | 24 | 78% | UKCA CE | ||
| SAB05-R2 Series | 5 | 85-305 | 210-1000 | 3.3-24 | - | UKCA CE | - | |
| SAB05-S03R2 | 5 | 85-305 | 1000 | 3.3 | 67% | UKCA CE |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
