Flyback transformer Filter Models: 7 in total, please see the table below.
| Series | Rated power（W） | Input voltage（V） | Output(AUX) | Output(S1) | Output(S2) | Output(S3) | Output(S4) | Output(S5) | Inductance | Spec. | Sample Application |
| FAT74XXX(EE16) | 1.5-12W | 85-265V | More | - | - | - | - | - | 1660-6000uH | - | - |
| FAT74000 | 5W | 85-265V | 7-14V,0.1A | 3.3-7V,1.2A | 8-17V,0.4A | - | - | - | 3900uH | ||
| FAT74001 | 6W | 85-265V | 8-16V,0.1A | 3-6V,1.2A | - | - | - | - | 3000uH | ||
| FAT74002 | 6W | 85-265V | 8.5-17V,0.1A | 9-18V,0.5A | - | - | - | - | 3000uH | ||
| FAT74003 | 5W | 85-265V | 8-16V,0.1A | 2-4V,1.8A | 3-6V,1.2A | - | - | - | 3000uH | ||
| FAT74090 | 1.5W | 85-265V | - | 3.3-6V,0.4A | - | - | - | - | 6000uH | ||
| FAT74091 | 1.5W | 85-265V | - | 7.5-15V,0.2A | - | - | - | - | 6000uH | ||
| FAT74092 | 3.1W | 85-265V | - | 3.3-6V,0.9A | - | - | - | - | 4200uH | ||
| FAT74093 | 3.1W | 85-265V | - | 7.5-15V,0.4A | - | - | - | - | 4200uH | ||
| FAT74094 | 9W | 85-265V | - | 3.3-6V,1.5A | - | - | - | - | 2100uH | ||
| FAT74095 | 9W | 85-265V | - | 7.5-15V,09A | - | - | - | - | 2100uH | ||
| FAT74010 | 12W | 85-265V | 7-14V,0.1A | 3.3-7V,2A | 8-17V,1A | - | - | - | 1660uH | ||
| FAT74014 | 12W | 85-265V | 9-18V,0.2A | 15-30V,0.4A | 15-30V,0.4A | - | - | - | 1800uH | ||
| FAT74015 | 12W | 85-265V | 12V,0.2A | 5A,1.5A | 15V,0.6A | - | - | - | 1800uH | ||
| FAT74XXX(EL19) | 16-18W | 85-265V | More | - | - | - | - | - | 900-1250uH | - | - |
| FAT74020 | 18W | 85-265V | 7-14V,0.1A | 3.3-7V,3A | 8-16.5V,1.4A | - | - | - | 1250uH | ||
| FAT74021 | 18W | 85-265V | 7-14V,0.1A | 3.3-7V,3A | 8-16.5V,1.4A | - | - | - | 900uH | ||
| FAT74023 | 16W | 85-265V | 15V,0.2A | 3.3V,2A | 5V,Sum S1+S2 | 12V,0.8A | 18V,0.8A | 30V,0.2A | 1250uH | ||
| FAT74XXX(EF20) | 20-24W | 85-265V | More | - | - | - | - | - | 1000-1300uH | - | - |
| FAT74080 | 24W | 85-265V | 11-8V,0.3A | 9-5V,1.5A | 9-15V,1.5A | - | - | - | 1000uH | ||
| FAT74082 | 20W | 85-265V | 7-18V,0.3A | 3-7.5V,2.0A | 3-7.5V,2.0A | - | - | - | 1300uH | ||
| FAT74081 | 20W | 85-265V | 15V,0.3A | 3.3V,3A | 5V,Sum S1+S2 | 12V,1.3A | - | - | 1100uH | ||
| FAT74XXX(EF25) | 30-35W | 85-265V | More | - | - | - | - | - | 750-1100uH | - | - |
| FAT74030 | 30W | 85-265V | 7-14.5V,1A | 3.3-7V,3A | 8-16V,1.5A | 8-16V,1.5A | - | - | 750uH | ||
| FAT74032 | 35W | 85-265V | 8-16V,1A | 15-30V,1.4A | - | - | - | - | 1100uH | ||
| FAT74XXX(ETD29) | 60-90W | 85-265V | More | - | - | - | - | - | 500uH | - | - |
| FAT74043 | 60W | 85-265V | 15V,0.5A | 3.3V,S1+S2:7A | 5V,S1+S2:7A | 12V,2A | 18V,2A | 30V,0.5A | 500uH | ||
| FAT74050 | 90W | 85-265V | 7-14V,0.5A | 3.3-6.5V,5A | 8.5-17V,3A | 3.3-6.5V,5A | 8.5-17V,3A | - | 500uH | ||
| FAT74XXX(ETD39) | 90W | 85-265V | More | - | - | - | - | - | 440uH | - | - |
| FAT74060 | 90W | 85-265V | 7-14V,0.5A | 3.3-6.5V,5A | 8.5-17V,5A | 3.3-6.5V,5A | 8.5-17V,5A | - | 440uH | ||
| FAT74XXX(ETD44) | 180W | 85-265V | More | - | - | - | - | - | 300uH | - | - |
| FAT74070 | 180W | 85-265V | 7-14V,0.5A | 3.3-6.5V,6A | 8.5-17V,5A | 3.3-6.5V,6A | 8.5-17V,5A | - | 300uH |
* The above product parameters are for reference only, please refer to the technical specifications for detailed technical parameters
